To remove block-out keys, pull straight up.
NOTE: Be sure block-out keys and /or dime inserts are seated
properly and ratchet dog is in place with irs spring connected
(see FIGURE 8).
Be sure the proper coin sizing block is in place.
Block-Out
Keys
FIGURE 8
Change coin sizing block:
• Remove two screws that hold upper coin chute cover.
Remove cover (see FIGURE 9).
(2) Upper Coin
Chute Cover
Screws
(2) Coin Sizing
Block Screws
FIGURE 10
• Remove two screws that hold coin sizing block to upper coin
chute cover cover (see FIGURE 10).
• Put new coin sizing block in place. Reinsert and tighten
mounting screws.
• Replace coin chute cover. Reinsert and tighten screws.
Ratchet
Dog and
Spring
Anti-Cheat
FIGURE 9
Coin Sizing
STEP 7
Replace coin receiver block into slide:
• Hold coin receiver right side up in the palm of one hand.
• Lower coin slide until coin receiver block fits into the coin
slide cavity. CAUTION: Do not dislodge ratchet dog and
spring.
• Hold coin receiver block in place with your fingers and turn
slide upside down.
• Insert and tighten screw.
STEP 8
Install slide into coin chute. Slide can only be pushed in if the
anti-cheat gate in flange is pushed to the left. (see FIGURE 9).
STEP 9
Replace coin slide stop with two screws. Replace coin slide
return spring. Replace coin slide extension with two screws (be
sure spacers are in place).
STEP 10
Replace coin slide mechanism in meter case. Replace and tighten
Gate
coin slide mounting bolt.
NOTE: It may be easier to insert coin slide mounting bolt if you
remove the timer from the mounting screws temporarily.
If replacement parts are needed for your dryer, contact the source
where you purchased your dryer, or call Sears Parts and Service
Toll Free Number 1-800-4-MY-HOME (1-800-469-4663).
box parts, call 1-800-221-0982, Greenwald Industries.
servicing controls. Wiring errors can cause improper and
dangerous operation. Verify proper operation after servicing.
Block
dryer is unpacked. Children might use them for play. Cartons
covered with rugs, bedspreads, or plastic sheets can become
airtight chambers causing suffocation. Place all materials in a
garbage container or make materials inaccessible to children.
literature included with this dryer are not meant to cover every
possible condition and situation that may occur. Good safe
practice and caution MUST be applied when installing, operating
and maintaining any appliance.
12

REPLACEMENT PARTS

Label all wires prior to disconnection when
Destroy the carton and plastic bags after the
The instructions in this manual and all other
For coin
