Universal pan: For cooking large quantities of food such
as moist cakes, pastries, frozen food etc,
or for collecting fat/ spillage and meat juices.
SHELF PLACEMENT WARNING:
To ensure the oven shelves operate safely, correct placement of the shelves
between the side rails is imperative. This will ensure that during careful removal
of the shelf or tray, hot food items should not slide out.
use of rotisserie accessories
The rotisserie works in combination with the grill element to cook cuts of
meat or poultry,at the same time browning to perfection.
NOTE: The number of a accessories included depends on the particular
appliance pruchased.
BULB REPLACEMENT
The bulb in the light is a special bulb, and has hight temperature resistance (230-240~25W).
For replacement, proceed as follows:
1. Disconnect power from the mains outlet or switch off the circuit breaker of the unit's mains outlet.
2. Unscrew the covering glass and replace the bulb with a new one of the same type.
3. Screw the covering glass back in place.
D
A
F

INSTALLATION

C
E
b
A
Model Dimension(mm) Model
A 600+2 B
C 560+2 D
E
24+2 F
G 25+2
5
A
F
Dimension(mm)
565+2
90
5
G
C
E
b
A
