Rubine RMO-IAM6-35GX User Manual

Microwave-grilling oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EXPOSURE TO EXCESSIVE MICROWAVE
EXPOSURE TO EXCESSIVE MICROWAVE
READ these instructions carefully before installing and operating the oven. Keep them for further reference.
1.
Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure
to microwave energy. It is important not to defeat or tamper with the safety interlocks.
2.
Do not place any object between the oven front panel and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
3.
Do not operate the oven if it is damaged. It is particularly important that the oven door closed properly and that
there is no damage to the oven.
a)
Door (bent),
b)
Hinges and latches (broken or loosened),
c)
Door seals and sealing surfaces.
4.
The oven should not be adjusted or repaired by anyone except properly qualified service personnel.
Microwave-Grilling Oven
User Manual
RMO-IAM6-35GX
PRECAUTIONS TO AVOID POSSIBLE
PRECAUTIONS TO AVOID POSSIBLE
ENERGY
ENERGY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RMO-IAM6-35GX and is the answer not in the manual?

Questions and answers

Related Manuals for Rubine RMO-IAM6-35GX

Summary of Contents for Rubine RMO-IAM6-35GX

  • Page 1 Microwave-Grilling Oven User Manual RMO-IAM6-35GX PRECAUTIONS TO AVOID POSSIBLE PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ENERGY READ these instructions carefully before installing and operating the oven. Keep them for further reference. Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy.

  • Page 2: Table Of Contents

    CONTENTS PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ....0   1.TECHNICAL SPECIFICATION........................... 2   2.PRECAUTIONS FOR USE ..........................2   3.SAFETY PRECAUTIONS ............................ 3   4.GET TO KNOW YOUR OVEN ..........................4   5.BEFORE INSTALLATION............................

  • Page 3: Technical Specification

    1. TECHNICAL SPECIFICATION. MODEL MG1035ES CAPACITY（L） VOLTAGE （V） /FREQUENCY （Hz） 220-240/50 DISTRIBUTION LINE FUSE（A）/CIRCUIT BREAKER（A） MICROWAVE INPUT WAVE（W） 1500-1600 MICROWAVE OUTPUT POWER（W） 1000 MICROWAVE WORKING FREQUENCY 2450 （MHz） GRILLING POWER（W） 1400-1650 PRODUCT DIMENSION（mm） 594×530×455 PACKAGE SIZE（mm） 675×611×525 DIAMETER OF ROTATING PLATE（mm） GROSS/NET WEIGHT（Kg）...

  • Page 4: Safety Precautions

    The nameplate with the technical data, serial number and mark is in a visible position on the oven door frame. The nameplate should never be removed. The appliance should be connected to earth in compliance with electrical system safety regulations. If a permanent connection is used, the appliance’s power supply wire should be fitted with a polar breaking device with contact gap of at least 3 mm, located in an easily accessible position close to the appliance itself.

  • Page 5: Get To Know Your Oven

    capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. – Children should be supervised to ensure that they do not play with the appliance. –...

  • Page 6: Before Installation

    5.BEFORE INSTALLATION The inside of the appliance should be cleaned to remove all manufacturing residues. For further information about cleaning, see point ‘Cleaning and Maintenance’. 6.DESCRIPTION OF FRONT PANEL CONTROLS All the appliance’s control and monitoring device are placed together on the front panel. The table below displays icons of different functions.
  • Page 7 8.2 Selecting the function Under the standby mode, all of the functions show on DSP3 after press PT2. Then turn PT2 to select the function, and the selected function will be displayed on DSP3, while the preset cooking time will be displayed on DSP1 and the preset parameters ( microwaves power, weight) are displayed in alternation on DSP2.
  • Page 8 CHEESE TOPPED SOUP 2×200G CUPS ONION SOUP BOWLS 8.6 Pizza function After selecting this function “ ”, the indicator “ ” “ ” light up, press PT1 to adjust the weight of pizza, weight indicator “ ” light up; After selecting the weight, press PT1, “ ”...

  • Page 9: Recommended Baking Menu

    interrupted. Proceed as follows: ● Turn PT2 to the right or left to change the function. ● Press PT1 to activate the parameter modification mode. “ ” indicator starts to blink. Turn PT1 to the right or left to change the remaining cooking duration ●...
  • Page 10 ● When cooking food with very little moisture (e.g. defrosting bread, making popcorn, etc.) evaporation is very quick. The oven then works as if it was empty and the food may burn. The appliance and the container may be damaged in such situation. You should therefore set just the cooking time necessary and you should keep a close eye on the cooking process.
  • Page 11 into contact with the oven inner cavity of the oven as this may cause electrical arcing. 5. Thick portions of food should be turned over several times in the process of baking. 6. Distribute the frozen food as evenly as possible since narrow and thick portions defrost more quickly than the thicker and broader parts.
  • Page 12 9.3. Cooking with the Grill For a better baking, use the rack supplied. Insert the rack in the way that it doesn’t come into contact with the metal surface of the oven cavity in case any danger of electric arcing which may damage the oven. IMPORTANT POINTS: 1.

  • Page 13: Cleaning And Maintenance

    In the case of the grill function, the ovenware should be resistant to temperature of at least 300℃. Plastic dishes are not suitable for the grill function. 9.7 Combination functions In the combination functions (microwave + conventional heating elements), the ovenware used should be suitable for microwave and grill.

  • Page 14: Special Maintenance

    If the oven cavity is very dirty, put a glass of water on the turntable and switch on the microwave oven for 2 or 3 minutes at maximum power. The steam released will soften the dirt which can then be cleaned easily using a soft cloth.
  • Page 15 12.3 Positioning the Microwave Oven If we put the Microwave Oven into cabinet, the material cabinet should be insulated, and the clearance between the edge of the cabinet and the Microwave Oven should be over 100 mm for ventilation. 14  ...
  • Page 16 There are 4 screws on the inner side of the oven door frame.                             Note: Do not take the door handle as force bearing point during the installation and removal.  ...

  • Page 17: Trouble Shooting

    13. TROUBLE SHOOTING Warning: Maintenance should be done by a professional mechanic. Circumstances that doesn’t need a professional mechanic With no display！ ■ Check the time indicator on or off With no response after press any button! ■ Check if safety lock is on or not. Oven doesn’t work! ■...
  • Page 18 17  ...
