QUICK INSTALLATION GUIDE
IMPORTANT
Do not apply power to the thermostat or wireless
sensor until instructed to do so.
For proper operation of the RF wireless
communication, when installing:
Avoid locating thermostat or sensor near any
wireless or noise generating devices, particularly
radio devices that operate in the range of 418 to
428 MHz.
Be sure that there are no electrical wires, metal
pipes or ductwork in the part of the wall chosen for
thermostat or sensor location
Avoid locating the thermostat or sensor on a
concrete wall, metal junction box or metal plate.
Thermostat antenna wire must be installed into the
wall. Do not allow the antenna wire to be between
the thermostat and the wall.
Thermostat must have uninterrupted 24VAC for
proper communication.
Any of the above can diminish or prevent proper
RF communication for this kit. Be sure to perform
a thorough checkout and confirm signal strength
between thermostat and wireless sensor.
FAILURE TO READ AND FOLLOW ALL
!
INSTRUCTIONS CAREFULLY BEFORE
INSTALLING OR OPERATING THIS
CONTROL COULD CAUSE PERSONAL INJURY
AND/OR PROPERTY DAMAGE.
Read Installer Notes
before removing cover
from Thermostat.
System Power
Thermostat is received from the factory for system
power to be hardwired with a common wire connected to
terminal C. If no common wire is available, the thermo-
stat will use Power Stealing and must be configured.
See Thermostat 24VAC Requirement on page 5.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
www.white-rodgers.com
www.emersonclimate.com
1F85RF-275
Wireless Remote Kit
Index
INSTALLER NOTES
Page
2
4
4
5
6
8
10
14
17
18
PART NO. 37-6841E
Replaces 37-6841C and D
1039
1
