SELECTING PRINTING FUNCTIONS

Almost all print functions are selected in the print driver properties window that appears when printing from an
application. The print functions can also be selected in the printer driver properties window that appears when
[Properties] is selected in the printer icon menu. The printer driver settings are grouped on tabs in the printer driver
properties window.
The procedure for selecting settings after opening the printer driver properties from an application is explained in this
section. (The screens show selection of the im4511 PCL6 printer driver in Windows Me. The screens differ slightly
when a hard disk drive is not installed.)
The following optional peripheral devices are installed in the printer driver windows:
B/W scanner module/DSPF + Saddle stitch finisher + Mail-bin stacker + Punch module + Duplex module

Settings in the [Main] tab

The following window appears when the [Main] tab is clicked. The settings and buttons are explained below.
(1)
(2)
(3)
(1) Copies
Set the number of copies.
Any number from 1 to 999 can be set.
Default setting: 1
(2) Collate
Select this checkbox to collate the copies.
When the staple function or punch function is
turned on, a checkmark automatically appears in
the checkbox.
Default setting: Selected
(3) Document Style
Select one-sided or two-sided printing.
[1-Sided]...................Print on one side of the
[2-Sided (Book Style)] ...Print on both sides of the
[2-Sided (Tablet Style)].. Print on both sides of the
[Booklet Mode] .......Print on both sides of the
*1
Default setting: 1-Sided
Four selections are available for the booklet
*1
format.
paper.
paper and bind at the side.
paper and bind at the top.
paper and bind down the
middle.
Click this button to return all
settings
default
button appears on all tabs.
[Tiled Booklet]
Print on paper double the size of the document size
selected in the application.
The page order will be rearranged as required for
the middle binding format.
[2-Up Booklet]
The document size selected in the application will
be reduced in the same way as in 2-Up printing,
and printing will take place using the selected
paper size.
[Multiple Tiled Booklet]
When using the booklet function, printing takes
place on paper that is twice the size of the paper
specified in the application. When this function is
selected and the number of pages exceeds the
stapling limit, the pages are divided into groups that
can be stapled, and the pages in each group are
arranged booklet mode and stapled. The groups
can then be put together to form a booklet with the
correct page order.
[Multiple 2-Up Booklet]
When using the booklet function, the pages are
reduced and printed 2-Up style on the size of the
paper specified in the application. When this
function is selected and the number of pages
exceeds the stapling limit, the pages are divided
into groups that can be stapled, and the pages in
each group are arranged booklet mode and
stapled. The groups can then be put together to
form a booklet with the correct page order.
2-2
to the factory
settings. This
