Instruction
manual
Model
H650CS
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 25
FRANÇAIS: PAGE 49
Generator
Shown with optional portability kit
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the frame.
Record these numbers in the spaces below and retain for
future reference.
Model No.
Type
Serial No.
Part No. D29463-036-0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H650CS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Porter-Cable H650CS

Summary of Contents for Porter-Cable H650CS

  • Page 1 Generator Model H650CS Shown with optional portability kit IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before http://www.porter-cable.com starting operations.

  • Page 2: Consumer Safety Information

    CONSUMER GENERAL AND SERVICE INFORMATION • Please read and follow these instructions for proper use and maintenance. • If you experience any problems and need assistance, please call us at our toll free number 1-888-559-8550, Monday through Saturday, 8:00 a.m. To 6:00 p.m.

  • Page 3: Safety Guidelines - Definitions

    SAFETY GUIDELINES / DEFINITIONS This manual contains information that is important for you to know and understand. This infor- mation relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections.
  • Page 4 RISK OF ELECTROCUTION AND FIRE (Continued) HAZARD HOW TO PREVENT IT WHAT CAN HAPPEN Operation of Water is an excellent conductor Operate generator in a clean, dry, generator in rain, of electricity! Water which comes well ventilated area. Make sure wet, icy, or in contact with electrically hands are dry before touching...

  • Page 5: Risk Of Fire

    RISK OF FIRE HAZARD HOW TO PREVENT IT WHAT CAN HAPPEN Gasoline and gasoline vapors Attempting to Turn engine off and allow it to can become ignited by coming fill the fuel tank cool before adding fuel to the in contact with hot components while the engine tank.

  • Page 6: Risk Of Unsafe Operation

    RISK OF INJURY AND PROPERTY DAMAGE WHEN TRANSPORTING GENERATOR HAZARD HOW TO PREVENT IT WHAT CAN HAPPEN Fuel or oil can leak or spill and Fire, Inhalation, If generator is equipped with a could result in fire or breathing Damage to fuel shut-off valve, turn the valve hazard, serious injury or death Vehicle Surfaces...

  • Page 7: Risk Of Hot Surfaces

    RISK OF UNSAFE OPERATION (Continued) HAZARD HOW TO PREVENT IT WHAT CAN HAPPEN Any gasoline operated Operation of Always use a U.L. listed voltage household generator will incur voltage sensitive surge protector to voltage variations causing sensitive appli- connect voltage sensitive damage to voltage sensitive ap- ances without a appliances (TV, computer, ste-...

  • Page 8: Risk Of Moving Parts

    Lifting a very lifted by one person. Obtain as- tempting to lift too heavy an heavy object. sistance from others before you object. try to move it. SPECIFICATIONS MODEL H650CS HORSE POWER RATED/SURGE WATTS 6500/12500 VOLTAGE 120/240 AMPERAGE 54.2/27.1A PHASE...

  • Page 9: Grounding The Generator

    ASSEMBLY Read this manual. Do not attempt to operate equipment until you have read this Manual for Safety, Operation, and Maintenance Instructions. NOTE: This manual is a general manual. Information in this manual may or may not pertain to your model. Please read carefully. NOTE: Left and right describes the location of a part with the operator facing the outlet panel.

  • Page 10: Extension Cords

    OBTAINING ELECTRICITY FROM THE GENERATOR There are basically 2 ways to obtain electricity from a generator: Use of extension cords directly from the generator to the appliance, lights, tools, etc. Use of a double-throw transfer switch installed directly to the main electrical supply outside of house.

  • Page 11: Operation

    OPERATION KNOW YOUR GENERATOR Read this General Manual and Safety Rules before operation of your Generator. Compare the illustration in your parts manual with your generator to familiarize yourself with the location of various controls and adjustments. Save all manuals for future references. GENERATOR CAPACITY IMPORTANT: Exceeding the rated capacity of your generator can result in serious damage to your generator and connected electrical devices.

  • Page 12: Before Start-Up

    12V DC OUTLET IMPORTANT: Allow generator to run at no load for 5 minutes upon each initial start-up to allow engine to stabilize. IMPORTANT: When the unit is running the battery will charge. DO NOT connect the 12V DC cables to the generator’s battery. To charge battery: Using the 12V DC cables supplied, connect the red positive (+) 12V DC cable to the battery's positive (+) terminal.

  • Page 13: To Start The Engine

    TO START THE ENGINE Never run engine indoors or in enclosed, poor ventilated areas, engine exhaust contains carbon monoxide, an odorless and deadly gas. Open the fuel shut-off valve on tank and engine. Move the choke control located on the engine to "CHOKE" position. NOTE: No choke is required on warm engines.

  • Page 14: Stopping Engine

    Overloading the generator will cause power fluctuations and can damage equipment and appliances. Porter-Cable Corporation will only be responsible for damage to customer's equipment when the generator is determined to be defective. This determination will only be made by an authorized representative of Porter-Cable Corporation and this decision will be final.
  • Page 15 CONNECTING PROCEDURE FOR RAISING OR SUSPENDING GENERATORS Failure to properly connect lifting cables, chains, or straps can cause property damage, serious injury or death, and void the manufacturer's warranty. Always use cables, chains, or straps rated at 2000 lbs. working load or more to raise or suspend generator.

  • Page 16: Maintenance

    MAINTENANCE CUSTOMER RESPONSIBILITIES TABLE Before Every 25 Every 50 Every 100 each Hours of Hours of Hours of Every Every Every MAINTENANCE TASK Season Season Season Check oil level See Note 2 See Note 1 Change oil Clean Air Filter Assembly Check Spark Plug Prepare unit for storage if it is to remain Prepare Unit for Storage...

  • Page 17: Engine Preparation

    STORAGE If you are going to store your generator for more than 30 days, use the following information as a guide to prepare the generator for storage. Never store generator with fuel in the tank indoors or in enclosed, poorly ventilated areas, where fumes can reach an open flame, spark or pilot light as on a furnace, water heater, clothes dryer or other gas appliances.

  • Page 18: Wattage Calculations

    WATTAGE CALCULATIONS IMPORTANT Never exceed the rated capacity of your generator. Serious damage to the generator or appliance could result from an overload. 1. Starting and running wattage requirements should always be calculated when matching a generators wattage capacity to the appliance or tool. 2.
  • Page 19 STARTING WATTAGE REQUIREMENTS Some appliances and tools will list on the motor nameplate the starting and running voltage and amperage requirements. Use the following formula to convert voltage and amperage to wattage: Volts X Amp = Watts Example: 120 volts x 10 amps = 1200 watts To determine the approximate starting wattage requirement for most appliances and tools with inductive type motors, multiply the wattage that was calculated by 2 to 4 times to assure adequate generator capacity.
  • Page 20 HOUSEHOLD WATTAGE CALCULATOR DEVICES WITH HIGH STARTING (INDUCTIVE)LOADS APPLIANCE OR TYPICAL DEVICE LOAD DEVICE* WATTAGE** RUN WATTS TOTAL TIMES (X) START FACTOR REFRIGERATOR/ 2400 FREEZER 1800 SMALL REFRIGERATOR 2400 AIR COND.(ROOM) 7200 1000 2000 SUMP PUMP 1/2 HP 2400 FURNACE FAN 1/3 HP 1000 WELL PUMP 1/2 HP 2000...

  • Page 21: Troubleshooting Guide

    TROUBLESHOOTING GUIDE CORRECTION PROBLEM CAUSE Engine will not Add fuel or oil. Low on fuel or oil. start Turn to "ON" position Ignition switch in "Off" position. Faulty spark plug. Replace spark plug. Adjust choke accordingly. Choke in wrong position. Fuel shut-off valve in Open fuel shut-off valve.

  • Page 22: Limited Warranty

    • Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Porter-Cable Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.
  • Page 23 NOTES 23- ENG...

  • Page 24: Quick Facts

    QUICK FACTS CALL 1-888-559-8550 TO FIND A LOCAL AUTHORIZED SERVICE CENTER NEAR YOU FOR REPAIRS AND SERVICE PART PURCHASES ENGINE Use clean, fresh gasoline with a minimum 87 octane rating. Do not add gasoline during or immediately after use. Refer to engine owner's manual for oil recommendations. ENGINE OIL Most generators are equipped with a low-oil shutdown.
