Instruction
manual
Model
H451CS
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2002 Porter-Cable Corporation
ESPAÑOL: PÁGINA 23
FRANÇAIS: PAGE 45
Generator
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the frame.
Record these numbers in the spaces below and retain for
future reference.
Model No.
Type
Serial No.
Part No. D27243-028-0
Advertisement
Table of Contents
Related Manuals for Porter-Cable D27243-028-0
Summary of Contents for Porter-Cable D27243-028-0
- Page 1 Instruction manual Model H451CS To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2002 Porter-Cable Corporation ESPAÑOL: PÁGINA 23 FRANÇAIS: PAGE 45 Generator IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.
-
Page 2: Consumer Safety Information
CONSUMER GENERAL AND SERVICE INFORMATION • Please read and follow these instructions for proper use and maintenance. • If you experience any problems and need assistance, please call us at our toll free number 1-888-559-8550, Monday through Saturday, 8:00 a.m. To 6:00 p.m. -
Page 3: Safety Guidelines - Definitions
SAFETY GUIDELINES / DEFINITIONS This manual contains information that is important for you to know and understand. This infor- mation relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. - Page 4 RISK OF ELECTROCUTION AND FIRE (Continued) HAZARD Operation of Water is an excellent conductor generator in rain, of electricity! Water which comes wet, icy, or in contact with electrically flooded charged components can conditions. transmit electricity to the frame and other surfaces, resulting in electrical shock to anyone con- tacting them.
-
Page 5: Risk Of Fire
RISK OF FIRE HAZARD Gasoline and gasoline vapors Attempting to can become ignited by coming fill the fuel tank in contact with hot components while the engine such as the muffler, engine is running. exhaust gases, or from an electrical spark. Sparks, fire, hot Cigarettes, sparks, fires, or objects... -
Page 6: Risk Of Unsafe Operation
RISK OF INJURY AND PROPERTY DAMAGE WHEN TRANSPORTING GENERATOR HAZARD Fuel or oil can leak or spill and Fire, Inhalation, could result in fire or breathing Damage to hazard, serious injury or death Vehicle Surfaces can result. Fuel or oil leaks will damage carpet, paint or other surfaces in vehicles or trailers. -
Page 7: Risk Of Hot Surfaces
RISK OF UNSAFE OPERATION (Continued) HAZARD Any gasoline operated Operation of household generator will incur voltage voltage variations causing sensitive appli- damage to voltage sensitive ap- ances without a pliances or could result in fire. voltage surge protector Generator could fall causing Raising or serious injury or death to you or suspending... -
Page 8: Specifications
RISK OF MOVING PARTS HAZARD The generator contains parts Contact with which rotate at high speed during moving parts operation. These parts are can result in covered by guarding to prevent serious injury. injury. RISK FROM LIFTING HAZARD Serious injury can result from at- Lifting a very tempting to lift too heavy an heavy object. -
Page 9: Grounding The Generator
Read this manual. Do not attempt to operate equipment until you have read this Manual for Safety, Operation, and Maintenance Instructions. NOTE: This manual is a general manual. Information in this manual may or may not pertain to your model. Please read carefully. NOTE: Left and right describes the location of a part with the operator facing the outlet panel. -
Page 10: Extension Cords
OBTAINING ELECTRICITY FROM THE GENERATOR There are basically 2 ways to obtain electricity from a generator: Use of extension cords directly from the generator to the appliance, lights, tools, etc. Use of a double-throw transfer switch installed directly to the main electrical supply outside of house. -
Page 11: Operation
KNOW YOUR GENERATOR Read this General Manual and Safety Rules before operation of your Generator. Compare the illustration in your parts manual with your generator to familiarize yourself with the location of various controls and adjustments. Save all manuals for future references. GENERATOR CAPACITY IMPORTANT: Exceeding the rated capacity of your generator can result in serious damage to your generator and connected electrical devices. -
Page 12: Before Start-Up
12V DC OUTLET IMPORTANT: Allow generator to run at no load for 5 minutes upon each initial start-up to allow engine to stabilize. IMPORTANT: When the unit is running the battery will charge. DO NOT connect the 12V DC cables to the generator’s battery. To charge battery: Using the 12V DC cables supplied, connect the red positive (+) 12V DC cable to the battery's positive (+) terminal. -
Page 13: To Start The Engine
TO START THE ENGINE Never run engine indoors or in enclosed, poor ventilated areas, engine exhaust contains carbon monoxide, an odorless and deadly gas. Open the fuel shut-off valve on tank and engine. Move the choke control located on the engine to "CHOKE" position. NOTE: No choke is required on warm engines. -
Page 14: Stopping Engine
Overloading the generator will cause power fluctuations and can damage equipment and appliances. Porter-Cable Corporation will only be responsible for damage to customer's equipment when the generator is determined to be defective. This determination will only be made by an authorized representative of Porter-Cable Corporation and this decision will be final. -
Page 15: General Recommendations
CUSTOMER RESPONSIBILITIES TABLE MAINTENANCE TASK Check oil level Change oil Clean Air Filter Assembly Check Spark Plug Prepare Unit for Storage Note 1: Change oil after first two (2) operating hours and every 50 operating hours thereafter, more often if operated in extreme dusty or dirty conditions. Note 2: Check oil after 5 hours of operation. -
Page 16: Engine Preparation
If you are going to store your generator for more than 30 days, use the following information as a guide to prepare the generator for storage. Never store generator with fuel in the tank indoors or in enclosed, poorly ventilated areas, where fumes can reach an open flame, spark or pilot light as on a furnace, water heater, clothes dryer or other gas appliances. -
Page 17: Wattage Calculations
WATTAGE CALCULATIONS Never exceed the rated capacity of your generator. Serious damage to the generator or appliance could result from an overload. 1. Starting and running wattage requirements should always be calculated when matching a generators wattage capacity to the appliance or tool. 2. - Page 18 STARTING WATTAGE REQUIREMENTS Some appliances and tools will list on the motor nameplate the starting and running voltage and amperage requirements. Use the following formula to convert voltage and amperage to wattage: Volts X Amp = Watts Example: 120 volts x 10 amps = 1200 watts To determine the approximate starting wattage requirement for most appliances and tools with inductive type motors, multiply the wattage that was calculated by 2 to 4 times to assure adequate generator capacity.
- Page 19 HOUSEHOLD WATTAGE CALCULATOR DEVICES WITH HIGH STARTING (INDUCTIVE)LOADS RUN WATTS TIMES (X) START FACTOR 2400 1000 1000 CAUTION !! DO NOT CONNECT VOLTAGE SENSITIVE ELECTRONIC EQUIPMENT (TV SET, COMPUTER, ETC.) DIRECTLY TO YOUR GENERATOR. IF YOU USE THE GENERATOR TO POWER SENSITIVE EQUIPMENT YOU MUST USE A U.L.
-
Page 20: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM Engine will not start No electrical output Repeated circuit breaker tripping Generator overheating No auto idle DC does not have power with the circuit breaker depressed D27243 CAUSE Low on fuel or oil. Ignition switch in "Off" position. -
Page 21: Limited Warranty
• Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Porter-Cable Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser. -
Page 22: Quick Facts
CALL 1-888-559-8550 TO FIND A LOCAL AUTHORIZED SERVICE CENTER NEAR YOU FOR REPAIRS AND SERVICE PART PURCHASES ENGINE Use clean, fresh gasoline with a minimum 87 octane rating. Do not add gasoline during or immediately after use. Refer to engine owner's manual for oil recommendations. ENGINE OIL Most generators are equipped with a low-oil shutdown.
