Poulan Pro 2050WT Parts List

PARTS LIST NO.
530164192
Replaces
DATE
2/25/04
530164192 --- 10/24/03
WARNING
All repairs, adjustments and
maintenance not described in
the Operator's Manual must
be performed by qualified
service personnel.
11
12
16
15
14
13
36
37
Ref. Part No. Description
1. 530038227 Lever- -Switch
(Includes Pin)
2. 530016149 Spring- -Switch
3. 530015775 Screw
4. 530047192 Assy- -Fuel Cap
5. 530023877 Fitting
6. 530069216 Kit- -Fuel Line (Large)
7. 530015922 Nut- -Speed
8. 530056602 Assy- -Chassis
9. 530038406 Grommet- -Choke Knob
10. 530047989 Lever- -Choke
11. 530037809 Wire- -Throttle
12. 530071305 Kit- -Trigger & Lockout
13. 530014949 Assy. - - Clutch
14. 530015611 Washer- -Clutch
15. 530047061 Assy- -Drum W/brg.
16. 530015907 Washer - - Thrust
17. 530039187 Assy- -Flywheel
18. 530015127 Washer- -Flywheel
19. 530016134 Nut- -Flywheel
20. 530015920 Screw
=
NEW PART NUMBER FOR THIS IPL
n
WEED EATER PARTS LIST
PARAMOUNT
POULAN
Note: Illustration may differ from actual model due to design changes
3
2
1
7
8
9
10
34
35
40
39
38
Ref. Part No.
21. 530049337
22. 530069232
23. 530056402
24. 530015892
25. 530056798
26. 530027531
27. 530037817
28. 530016080
29. 530071666
30. 530015814
31. 530010846
32. 530016132
33. 530029850
34. 530015814
35. 530038238
36. 530054740
37. 530015917
38. 530069611
39. 530038593
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
R R
R r PARTS LIST PARTS LIST
R
PARTS LIST
TYPE 1---6
4
5
6
19
18
17
31
32
33
42
41
Description
Housing- -Fan
Kit- -Rope
Handle- -Starter
Screw
Handle- -Front
Spring- -Starter
Pulley- -Starter
Screw
Kit- -Oil Check Valve
Screw
Assy- -Oil Cap
Screw
Chain Catcher
Screw
Plate- -Bar Mounting
Assy- -Chain Brake
Nut- -Bar Mounting
Kit- -Bar Adjust
(incl. 39,40)
Retainer- -Bar Adjust
CHAIN SAW MODEL(s)
Poulan 2050 WT
PAGE NO.
23
22
21
20
24
26
27
28
25
Kit--Oil Check Valve
29
30
44
45 46
47
48
Ref. Part No. Description
40. 530015826 Pin- -Bar Adjust
Chain--- 14"
41. 952051209
Bar--- 14"
42. 952044368
43. 530015940 Screw
44. 530071259 Kit- -Oil Pump
(incl 45,46,48)
45. 530037820 Gear- -Worm Spring
46. 530049477 Elbow- -Oil Pickup
47. 530016064 Screw
48. 530019206 Seal Block
49. 530047663 Assy- -Oil- -Pickup
(Incl. 50- -51)
50. 530038373 Pickup- -Oiler
51. 530056533 Filter- -Oil
1
43
49
50
51
