Poulan Pro 2050 Parts List

PARTS LIST NO.
530083628
DATE
REPLACES
10/12/00
530083628---8/13/98
WARNING
All repairs, adjustments
and maintenance not de-
scribed in the Operator's
Manual must be performed
by qualified service per-
sonnel.
3
1
9
4
28
Chain
Brake
5
Kit
Ref. Part No. Description
1. 530069724 Trigger & Lockout Kit
(Includes Pin)
2. 530038593 Retainer--Bar Adjust
3. 530037809 Wire -- Throttle
4. -- Clutch Cover
530038236 2050, 2150
530049217 2175
530053712 2375--Wildthing
n
5. 530015917 Nut -- Bar Mounting
6. 530047989 Choke Lever
7. 530038406 Grommet--Choke Knob
8. 530069822 Chassis Ass'y. Kit
9. 530094188 Clutch Spring
10. 530047061 Assy.--Drum --w/Brg.
11. 530015611 Washer -- Clutch
12. 530014949 Clutch Ass'y.
13. 530038227 Switch Lever
14. 530016149 Switch Spring
15. 530015775 Screw
16. 530015922 Nut--Speed
17. 530029850 Chain Catcher
18. 530015814 Screw
19. 530015907 Washer -- Thrust
20. 530015826 Pin --Bar Adjusting
22. 530069611 Kit--Bar Adjust (Incl. 2)
=
NEW PART NUMBER FOR THIS IPL
n
=
D THESE PARTS ARE ILLUSTRATED FOR CLARITY.
POULAN r PARTS LIST
WEED EATER PARTS LIST
PARAMOUNT
POULAN
Note: Illustration may differ from actual model due to design changes
15
14
13 36
1
6 7 8 16
16
19
10
11
12
18
23
20
2
24
45 31
22
29
30
Ref. Part No.
23. 530038238
24. 530071259
26. 530016133
28. 952069662
29. 530016064
30. 530019206
31. 530049477
32. 530038373
33. 530037821
34. 530030189
35. 530010846
36. 530069216
38. 530047164
40. 530016080
41. 530047663
42. 530016020
43. 530016132
44. 530015814
45. 530037820
46. 530019231
47. 530037799
48. 530038224
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
ORDER COMPLETE ASSEMBLY.
R R
R PARTS LIST
R
PARTS LIST
64
38
59
57
56
26
65
61
58
43
63
17
41
32
33
34
Description
Bar Mounting Plate
Oil Pump Kit--(Incl. Oil
Pump Body, Gear Assy,
Pin, 31 & 45)
Bolt
Chain Brake Kit
Screw
Seal Block
Elbow--Oil Pickup
Pick--Up Oiler
Oil Filter
Plug-- Oil Filter
Oil Cap Ass'y.
Fuel Line Kit (Large)
Fuel Cap Ass'y.
Screw
Oil--Pickup Ass'y.
(Incl. 32, 33 & 34)
Screw
Screw
Screw
Gear Worm Spring
Dust Seal
Front Handle
Handguard
CHAIN SAW MODEL(s)
2050, 2150, 2175,
2375---Wildthing
PAGE NO.
50
53 52
51
54
55
60
52
40
47
42
35
44
48
62
Ref. Part No. Description
49. 530015940 Screw
50. 530037485 Starter Handle
51. 530069232 Rope Kit
52. 530015892 Screw
53. -- Fan Housing
n
530049334 2050, 2150
530049337 2175, 2375--Wildthing
54. 530027531 Starter Spring
55. 530037817 Starter Pulley
56. 530039209 Flywheel Ass'y.
57. 530015127 Washer--Flywheel
58. 530026119 Check Valve
59. 530016134 Nut--Flywheel
60. 530015920 Screw
61. 530038264 Plug -- Bronze Vent
62. 952051209 Chain---14"
952051211 Chain---16"
952051338 Chain---18"
63. 952044368 Bar---14"
952044370 Bar---16"
952044418 Bar---18"
Decorative Bar for 2175
D
is not available.
64. 530023877 Fitting
65. 530023817 Spring --- Starter Dog
1
49
