Summary of Contents for NETGEAR RT328

  • Page 2: Start Here

    Start Here Product illustrations Congratulations on your purchase of a NETGEAR Model RT328 or Model RH348 ISDN Router. ® These instructions show you how to configure your Windows PC network and your ™ NETGEAR router for basic Internet access through an ISDN connection to an Internet service provider (ISP).
  • Page 3 Front Panel of the Router The front panels of the Model RT328 router and the Model RH348 router are almost identical. The LAN LEDs are the main distinguishing feature. The table below describes all of the LEDs on the front panel of both routers.
  • Page 4 Refer to this diagram to identify all of the ports on the router when you attempt to make any connections. The Model RT328 router has an AUI port and one UTP LAN port. The Model RH348 router has four UTP LAN ports. Otherwise, the rear panels are identical.

  • Page 5: Hardware Installation

    Hardware Installation Refer to the following illustrations for installing and connecting your Model RT328 or Model RH348 router. ISDN wall connection POWER ISDN-U PHONE 1 PHONE 2 16VAC AC power adapter or hubs Phone or other analog devices Phone or other...

  • Page 6: Setup And Preparation

    If you require MultilinkPPP and/or compression, ask whether or not your ISP supports these features. Network Checklist The Model RT328/RH348 router uses the Internet Protocol (IP). The IP configuration has the following requirements: • All PCs must have TCP/IP manually installed and manually selected as the networking protocol.

  • Page 7: Connecting The Router

    For your ISDN connection, use the black cable that is provided. For your LAN connection: • Use a red crossover cable for connecting your Model RT328 router to a PC. • Use a white straight-through cable for connecting your Model RT328 router to an Ethernet hub.

  • Page 8: Configuring Tcp/Ip Properties By Dhcp

    At this point your PC is configured to obtain its TCP/IP configuration information automatically from a DHCP server on the local network. The Model RT328/RH348 router is shipped preconfigured as a DHCP server and will assign the TCP/IP configuration information described in the previous section.

  • Page 9: Launching Firstgear

    Your Model RT328/RH348 router is now fully configured to provide Internet access for your network. For more information about installing your router, refer to Reference Guide for the Model RT328 and Model RH348 ISDN Routers and Getting Started Using FirstGear for the Model RT328 and Model RH348 ISDN Routers.
  • Page 10 EN 55 022 Statement This is to certify that the Model RT328 ISDN Router and Model RH348 ISDN Router are shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class A (CISPR 22).

  • Page 11: Customer Support

    Santa Clara, CA 95054 USA Phone: 888-NETGEAR Customer Support Phone U.S./Canada: 800-211-2069 Europe: (44) 171-571-5120 United Kingdom: (44) 171-571-5120 France: 0800-90-2078 Germany: 0130-817305 Sweden: 020-790086 Australia: 800-14-20-46 New Zealand: 800-444-626 Korea: 00308-11-0319 Internet/World Wide Web The NETGEAR Web page is at http://NETGEAR.baynetworks.com *M2-RH348NA-0*...
