Summary of Contents for NETGEAR RT338 RT338 RT338
-
Page 2: Start Here
Router. This document provides instructions to get you connected to an ISDN Internet service line using the NETGEAR Model RT338 router and your personal computer. The document is only a quick reference guide. For more detailed information about installation and configuration, refer to Model RT338 ISDN Router Installation Guide included on the Model RT338 Resources CD. -
Page 3: Rear Panel
Rear Panel Refer to this diagram to identify all the ports on the router when you attempt to make any connections. Rear Panel of the Model RT338 Router AC adapter outlet POWER 12VDC LAN port Power switch Installing the Hardware Refer to the following illustration and steps when connecting the router. -
Page 4: Prepare The Router
Contact the ISDN sales center of the phone company and order an ISDN Basic Rate Interface (BRI) phone line. In North America, provide the phone company with an ISDN ordering code (IOC). NETGEAR recommends codes IOC “U” or EZ-ISDN1 for the Model RT338 router. Additional information about ordering an ISDN line can be found in the Model RT338 ISDN Router Installation Guide. -
Page 5: Setting Up An Isp
All PCs must also have other IP configuration information, including a subnet mask, a domain name server (DNS) address, and a default gateway address. This information is also assigned automatically by the Model RT338 router whenever a PC reboots. For more information about these parameters, refer to the Model RT338 ISDN Router Installation Guide. -
Page 6: Configuring The Pcs
Restart your PC after making these changes. Configuring TCP/IP Properties NETGEAR recommends that you keep the default settings for the TCP/IP setup parameters, because your PC is configured to obtain its TCP/IP configuration information from a DHCP server on the LAN. The Model RT338 router is shipped preconfigured as a DHCP server and assigns the TCP/IP configuration. -
Page 7: Verifying Tcp/Ip Properties
To configure your router, you will use the FirstGear that is provided on the Model RT338 Resources CD. To install and run FirstGear: 1. Insert the NETGEAR Model RT338 Resources CD. 2. From the Windows taskbar, open Start > Run. 3. Click on Browse. -
Page 8: Verifying The Installation
The Model RT338 router is now configured to provide Internet access for your LAN. For additional applications information, refer to the Applications folder on the Model RT338 Resources CD and on the NETGEAR Web site at: www.NETGEAR.com. Verifying the Installation When the router is configured correctly, it will place a call to the ISP... - Page 9 The Model RT338 router is now configured to provide Internet access for your LAN. For additional applications information, refer to the Applications folder on the Model RT338 Resources CD and on the NETGEAR Web site at: www.NETGEAR.com. Model RT338 ISDN Router Installation Guide...
- Page 10 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
- Page 11 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 Phone: 1-888-NETGEAR E-mail: support@NETGEAR.com http://www.NETGEAR.com *M1-RT338NA-3*...
