Summary of Contents for NETGEAR RT338

  • Page 2: Start Here

    Router Installation Guide included on the Model RT338 Resources CD. Product Illustration Front Panel The front panel of the Model RT338 router contains status LEDs. Refer to the illustration and table below for descriptions of the LEDs on the front panel of the router.
  • Page 3 (Link/Activity) Blinking ISDN 1 (Phone) 2 (Phone) Rear Panel Refer to this diagram to identify all the ports on the router when you attempt to make any connections. Rear Panel of the Model RT338 Router AC adapter outlet POWER 12VDC...

  • Page 4: Installing The Hardware

    Use the white straight-through cable included to connect the router to a • 10 Mbps or 100 Mbps hub or switch port. The router will sense the speed of the connected port and will automatically set its speed to match.

  • Page 5: Ordering An Isdn Line

    ISDN ordering code (IOC). NETGEAR recommends codes IOC “U” or EZ-ISDN1 for the Model RT338 router. Additional information about ordering an ISDN line can be found in the Model RT338 ISDN Router Installation Guide. When the ISDN line is installed, make sure you have the following information: •...

  • Page 6: Setting Up An Isp

    Using Private IP Addresses Using the DHCP protocol, the Model RT338 router assigns private IP addresses to all the PCs on your LAN (when the PC reboots). The Internet Engineering Task Force (IETF) reserves these addresses for use in private networks: •...

  • Page 7: Configuring The Pcs

    NETGEAR recommends that you keep the default settings for the TCP/IP setup parameters, because your PC is configured to obtain its TCP/IP configuration information from a DHCP server on the LAN. The Model RT338 router is shipped preconfigured as a DHCP server and assigns the TCP/IP configuration.

  • Page 8: Verifying Tcp/Ip Properties

    7. Verify that the DNS server is set to 192.168.0.1. Configuring the Router To configure your router, you will use the FirstGear that is provided on the Model RT338 Resources CD. To install and run FirstGear: 1. Insert the NETGEAR Model RT338 Resources CD.

  • Page 9: Verifying The Installation

    Model RT338 ISDN Router Installation Guide. The Model RT338 router is now configured to provide Internet access for your LAN. For additional applications information, refer to the Applications folder on the Model RT338 Resources CD and on the NETGEAR Web site at: www.NETGEARinc.com.

  • Page 10: Troubleshooting Information

    FirstGear cannot find your router: • Check the Ethernet connection between your PC and router. The Link LED on your Ethernet card and the corresponding port LED on the router should be lit. • Power cycle the router. Wait 1 minute before starting FirstGear.
  • Page 11 DNS servers for use. Follow the steps described in “Verifying TCP/ IP Properties” to verify that a DNS server address is present. The Model RT338 router is now configured to provide Internet access for your LAN. For additional applications information, refer to the Applications folder on the Model RT338 Resources CD and on the NETGEAR Web site at: www.NETGEARinc.com.
  • Page 12 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 13 NETGEAR, Inc. A Bay Networks Company 4401 Great America Parkway Santa Clara, CA 95054 USA Phone: 888-NETGEAR http://www.NETGEARinc.com *M1-RT338NA-2*...
