Table of Contents

www.weslo.com
Model No. WLEX31712.0
Serial No.
Write the serial number in the space
above for reference.
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-699-3756
Mon.––Fri. 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial Number
Decal
USER’'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Purcuit4.2 Bike and is the answer not in the manual?

Questions and answers

Shirley Evans
February 5, 2025

How can I make the display lights brighter

0
1 comments:
Mr. Anderson
May 14, 2025

To increase the brightness of the display lights on the Weslo Purcuit 4.2 Bike, replace the batteries with new ones. A dim display is usually caused by low batteries.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Weslo Purcuit4.2 Bike

Summary of Contents for Weslo Purcuit4.2 Bike

  • Page 1 Model No. WLEX31712.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    If a decal is missing or illegible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new WESLO ® PURSUIT reading this manual, please see the front cover of this CT 4.2 exercise bike. Cycling is an effective exercise manual. To help us assist you, note the product model for increasing cardiovascular fitness, building number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    •• In addition to the included tool(s), assembly video, go to requires the following tools: http://productvideo.co/ one Phillips screwdriver assembly/kmart/weslo or use your mobile one adjustable wrench phone or smartphone to read the QR code at the one pair of pliers right.
  • Page 7 2. Attach the Rear Stabilizer (6) to the Seat Frame (5) with two M10 x 75mm Carriage Bolts (30) and two M10 Locknuts (48). 3. Insert the end of the Seat Frame (5) into the Frame (1). Firmly press the Frame Bushing (56) into the Frame (1).
  • Page 8 4. Attach the Left and Right Seat Brackets (14, 15) to the Seat Frame (5) with two M8 x 125mm Bolts (29), four M8 Washers (54), and two M8 Locknuts (10) as shown. Do not fully tighten the Locknuts yet. 5.
  • Page 9 6. Attach the Backrest (60) to the Seat Brackets (14, 15) with four M6 x 35mm Screws (61) and four M6 Washers (32). 7. Attach the Seat (12) to the Seat Brackets (14, 15) with four M6 x 35mm Screws (61) and four M6 Washers (32).
  • Page 10 8. Have a second person hold the Upright (13) near the Frame (1) until step 9. Connect the Extension Wire (52) to the Reed Wire (43). Then, connect the Resistance Cable (19) to the Lower Resistance Cable (45) in the following way: ••...
  • Page 11 10. Hold the Handlebar (53) near the Upright (13). Insert the two Pulse Wires (67) into the Upright, and then pull the Pulse Wires out of the top of the Upright. Tip: Avoid pinching the wires. Attach the Handlebar (53) to the Upright (13) with two M8 x 65mm Bolts (36), two M8 Curved Washers (46), and two M8 Locknuts (10).
  • Page 12 12. While a second person holds the Console (16) near the Upright (13), connect the console wires to the two Pulse Wires (67), the Extension Wire (52), and the Ground Wire (65). Then, insert the wires into the Upright (13). Tip: Avoid pinching the wires.

  • Page 13: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO ADJUST THE SEAT FRAME To adjust the seat frame, first loosen the adjustment knob on the frame. Slide the seat frame forward or For effective exercise, the seat should be in the proper backward to the desired position.
  • Page 14 CONSOLE DIAGRAM HOW TO USE THE MANUAL MODE 1. Turn on the console. To turn on the console, press the On/Reset button or begin pedaling. The entire display will turn on for a moment; the console will then be ready for use. 2.
  • Page 15 Note: The console can show pedaling speed and To reset the display, press the On/Reset button. distance in either miles or kilometers. To change To pause the console, stop pedaling. When the the unit of measurement, see THE USER MODE console is paused, the time will flash in the display.
  • Page 16 HOW TO USE A QUICK PACE WORKOUT If your pedaling speed is slower than the cur- rent target speed, an arrow will appear next to the 1. Turn on the console. RPM meter to prompt you to increase your speed; if your pedaling speed is faster than the target To turn on the console, press the On/Reset button speed, an arrow will prompt you to decrease your...
  • Page 17 THE USER MODE The display will show the selected unit of measure- ment. An E for English miles or an M for metric The console features a user mode that allows you to kilometers will appear in the display. To change the select a unit of measurement for the console.

  • Page 18: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike Turn the Resistance Knob (27) to the lowest setting. regularly. Replace any worn parts immediately. Then, locate the Reed Switch (43). Turn the Pulley (21) until the Magnet (38) is aligned with the Reed Switch. To clean the exercise bike, use a damp cloth and a Loosen, but do not remove, the M4 x 16mm Self- small amount of mild detergent.
  • Page 19 HOW TO ADJUST THE DRIVE BELT If you can feel the pedals slip while you are pedaling, even when the resistance is at the highest level, the drive belt may need to be adjusted. To adjust the drive belt, you must first remove the right pedal and the right shield as described below.

  • Page 20: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 21: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 22: Part List

    PART LIST Model No. WLEX31712.0 R0912A Key No. Qty. Description Key No. Qty. Description Frame M8 x 65mm Bolt Front Stabilizer Eddy Mechanism Handlebar Cap Magnet Wheel M5 Curved Washer Seat Frame M4 x 5mm Self-tapping Screw Rear Stabilizer M4 x 25mm Screw Seat Handle Cap M8 Split Washer Rear Stabilizer Cap...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING Model No. WLEX31712.0 R0912A...

  • Page 24: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
