  • Page 1 USER'S MANUAL Model No. WLEVEX1736.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 08457 089 009 Or write: ICON Health &...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new WESLO after reading this manual, please see the front cover ® PURSUIT T 149 exercise cycle. Cycling is one of the of this manual. To help us assist you, note the product...

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the includ- ed tools and your own adjustable wrench , Phillips screwdriver , and pliers...
  • Page 5 3. Attach the Left and Right Frame Covers (59, 3) around the Frame (1) with an M4 x 15mm Round Head Screw (60) and two M5 x 15mm Round Head Screws (61) as shown. 4. Attach the Seat (12) to the Seat Carriage (58) with four M8 Split Washers (42) and four M8 Nylon Locknuts (10).
  • Page 6 6. While another person holds the Upright (13) near the Frame (1) as shown, connect the Extension Wire (23) to the Reed Switch Wire (39). Next, con- nect the Resistance Cable (19) to the Lower Cable (29) in the following way: •...
  • Page 7 8. Attach the Pivot Bracket (53) to the Upright (13) with the Pivot Clamp (54) and the Pivot Handle (55). Be careful to Note: The Pivot Handle functions like a ratchet. Turn avoid pinching the Pivot Handle clockwise, pull it away from the the wires.

  • Page 8: How To Operate The Exercise Cycle

    HOW TO OPERATE THE EXERCISE CYCLE HOW TO ADJUST THE SEAT POST HOW TO ADJUST THE PEDALING RESISTANCE For effective exer- To increase the cise, the seat resistance of the should be at the pedals, turn the proper height. As resistance knob Seat you pedal, there...
  • Page 9 CONSOLE DIAGRAM HOW TO USE THE MANUAL MODE Turn on the console. To turn on the console, press the On/Reset button or begin pedaling. Select the manual mode. Each time you turn on the con- sole, the manual mode will be selected.
  • Page 10 In addition, the Measure your heart rate if desired. pace meter on the right side of Note: If there the display will are sheets of Metal provide a visual clear plastic on Contacts representation of the metal con- your pedaling tacts of the pace.
  • Page 11 As the target pace indicator changes in height HOW TO USE A PACE PROGRAM during the program, adjust your pedaling pace so that both indicators are the same height. If your Turn on the console. pedaling pace is slower than the current target pace setting, an upward arrow will appear next to See step 1 on page 9.

  • Page 12: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise cycle reg- Switch slightly closer to or away from the Magnet, and ularly. Replace any worn parts immediately. then retighten the Screw. Turn the Crank for a moment. Repeat until the console displays correct To clean the exercise cycle, use a damp cloth and a feedback.

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES The following guidelines will help you to plan your During the first few minutes of exercise, your body uses easily accessible carbohydrate calories for ener- exercise program. Remember that proper nutrition and adequate rest are essential for successful results. gy.

  • Page 14: Part List

    PART LIST—Model No. WLEVEX1736.0 R0906A Key No. Qty. Description Key No. Qty. Description Frame M8 x 15mm Button Screw Front Stabilizer Belt Right Frame Cover Crank Bearing Set Front Stabilizer Endcap Flywheel Seat Post Magnet Rear Stabilizer Reed Switch/Wire Handlebar Endcap M8 x 20mm Bolt Rear Stabilizer Endcap M4 x 25mm Round Head Screw...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEVEX1736.0 R0906A...

  • Page 16: Ordering Replacement Parts

    To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (WLEVEX1736.0) • the NAME of the product (WESLO PURSUIT T 149 exercise cycle) • the SERIAL NUMBER of the product (see the front cover of this manual) •...

This manual is also suitable for:

Wlevex1736.0Pursuit t 149
