USER'S MANUAL
Model No. WLEL81914.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
(under frame)
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today,
go to www.wesloservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.wesloservice.com.
Or call 1-866-699-3756
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for Weslo WLEL81914.0
Summary of Contents for Weslo WLEL81914.0
- Page 1 USER’S MANUAL Model No. WLEL81914.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal (under frame) ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.wesloservice.com/ registration. CUSTOMER CARE For service at any time, go to www.wesloservice.com.
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product. - Page 4 STANDARD SERVICE PLANS...
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary WESLO reading this manual, please see the front cover of this ® MOMENTUM G 3.4 elliptical. The MOMENTUM G 3.4 manual. To help us assist you, note the product model elliptical provides an impressive selection of features number and serial number before contacting us. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 7: Assembly
ASSEMBLY • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tools: one Phillips screwdriver • Assembly requires two persons. one adjustable wrench • Place all parts in a cleared area and remove the packing materials. - Page 8 3. Attach the Front Stabilizer (38) to the Frame (16) with two M8 x 65mm Carriage Bolts (57), two M8 Curved Washers (14), and two M8 Acorn Nuts (59) (only one side is shown); start both Carriage Bolts, and then tighten the Acorn Nuts.
- Page 9 5. Insert the excess wire and cable into the Frame (16). Tip: Avoid pinching the wire and the cable. Slide the Upright (32) onto the Frame (16). Attach the Upright (32) with four M8 x 16mm Screws (15) and four M8 Curved Washers (14); Avoid pinching start all the Screws, and then tighten them.
- Page 10 7. Attach the Water Bottle Holder (9) to the Upright (32) with two M5 x 20mm Screws (12); start both Screws, and then tighten them. 8. Using a plastic bag to keep your hands clean, apply a generous amount of the included grease to the right axle on the Upright (32).
- Page 11 9. Orient an Upper Body Arm (41) as shown and slide it onto the right Upper Body Leg (44). Attach the Upper Body Arm (41) with two M8 x 40mm Bolts (60), two M8 Curved Washers (14) and two M8 Acorn Nuts (59); start both Bolts, and then tighten the Acorn Nuts.
- Page 12 11. Identify the Right Pedal (56) and orient it as shown. Attach the Right Pedal (56) to the Right Pedal Arm (51) with three M6 x 35mm Bolts (63), six M6 Washers (62), and three M6 Locknuts (39). Attach the Left Pedal (54) to the Left Pedal Arm (46) in the same way.
- Page 13 13. While a second person holds the Console (1) near the Upright (32), connect the wire on the Console to the Upright Wire (33). Avoid pinching the wires Tip: Avoid pinching the wires. Attach the Console (1) to the Upright (32) with four M5 x 10mm Screws (2);...
-
Page 14: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO MOVE THE ELLIPTICAL HOW TO USE THE ELLIPTICAL Due to the size and weight of the elliptical, moving To mount the elliptical in the elliptical mode, hold the it requires two persons. Stand in front of the ellipti- upper body arms and step onto the pedal that is in the cal, hold the upright, and place one foot against one of lower position. - Page 15 HOW TO ADJUST THE PEDALING RESISTANCE To increase the resistance of the pedals, turn the resistance knob clockwise; to decrease the resis- tance, turn the knob counterclockwise. IMPORTANT: Stop turning the knob when turning becomes difficult, or damage may result. Resistance Knob...
- Page 16 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The easy-to-use console features five modes that provide instant exercise feedback during your workouts. Scan (SCAN)—This mode displays the time, speed, distance, and calorie modes, for a few seconds each, in a repeating cycle. Time (TMR)—This mode displays the elapsed time.
- Page 17 HOW TO USE THE CONSOLE 3. Begin pedaling and follow your progress with the displays. Make sure that batteries (not included) are installed in Scan mode—To select the scan mode, press the the console (see assembly step 12 on page 12). If there is a sheet of plastic on the console, remove the MODE button repeatedly until the word SCAN plastic.
-
Page 18: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 19: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE Locate the Reed Switch (18). Turn the Crank (3) until a Magnet (8) is aligned with the Reed Switch. Inspect and tighten all parts of the elliptical regularly. Replace any worn parts immediately. To clean the elliptical, use a damp cloth and a small amount of mild soap. - Page 20 HOW TO ADJUST THE DRIVE BELT If you can feel the pedals slip while you are pedaling, even when the resistance is at the highest level, the drive belt may need to be adjusted. To adjust the drive belt, first see assembly step 10 on page 11 and remove the Right Pedal Arm (51) from the right Upper Body Leg (44) and the right side of the Crank (3).
-
Page 21: Exercise Guidelines
EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian. -
Page 22: Part List
PART LIST Model No. WLEL81914.0 R1115A Key No. Qty. Description Key No. Qty. Description Console M5 x 14mm Screw M5 x 10mm Screw Rear Stabilizer Crank/Pulley Leveling Cap Eddy Mechanism Front Stabilizer Drive Belt M6 Locknut Bearing Assembly Front Stabilizer Cap/Wheel... -
Page 23: Exploded Drawing
EXPLODED DRAWING Model No. WLEL81914.0 R1115A... -
Page 24: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
