Removable Storage Drawer

The storage drawer is a good place to store cookware
and bakeware. Do not store plastics and flammable
material in the drawer.
Do not overload the storage drawer. If the drawer is
too heavy, it may slip off the track when opened. To
open the drawer, grasp the center of the handle and
pull straight out.
The storage drawer may be removed for cleaning under
the range.
Oven Interior Light
NOTE: The glass cover should be removed only
when cold. Wearing latex gloves may offer a
better grip.
The light bulb is located on the back wall of the oven.
Before replacing the bulb, disconnect electrical power
to the range at the main fuse or circuit breaker panel
or unplug the range from the electrical outlet. Let the
bulb cool completely before removing it. For your
safety, do not touch a hot bulb with a damp cloth. If
you do, the bulb will break.

Painted Surfaces

Painted surfaces include the outside oven door, sides, control panel and
drawer front. Clean these with soap and water or a vinegar and water
solution. Do not use commercial oven cleaners, cleansing powders, steel
wool or harsh abrasives on any painted surface.
Oven Vent Duct
The oven vent is located at the rear of the cooktop. Never cover the opening
with aluminum foil or any other material. This would prevent the oven vent
from working properly.
To remove:
• Pull the drawer straight out
and lift over the guide stops.
To replace:
• Lift over the guide stops and
slide the drawer into place.
To clean the inside and outside:
• Wash with soap and water. Rinse well. Do not use
cleansing powders or harsh abrasives which may
scratch the surface.
To remove:
Unscrew the cover
and remove the bulb.
To replace:
Put in a new 40-watt
appliance bulb.
NOTE:
• A 40-watt appliance bulb is smaller than a standard
40-watt household bulb.
• Install and tighten the cover.
• Reconnect electrical power to the range.
Socket
3 1 ⁄ Max. Length
2
Bulb
Glass Cover
35
