Feature Index
1 Surface Unit Controls
2 Surface Unit "On" Indicator Light
3 Oven Light Switch
4 AUTOMATIC OVEN Light
5 Clock and Timer
6 OVEN ON Light
AUTO SELF CLEAN Light
PREHEATED Light
7 Oven Temperature Knob
8 Oven Vent Duct
9 Cooktop Surface Units
10 Hot Surface Light
Light will glow when the cooktop is hot to the touch.
11 Broil Element
12 Oven Shelf Supports
Shelf positions are suggested in the
Baking, Roasting and Broiling sections.
13 Oven Shelf with Stop-Locks
14 Bake Element
May be lifted gently for wiping the oven floor.
15 Lift-Off Oven Door with Broil Stop Position
16 Broiler Pan and Grid
Do not clean in the self-cleaning oven.
17 Storage Drawer
18 Model and Serial Numbers
19 Anti-Tip Device
20 Oven Interior Light
21 Oven Door Latch
Use for self-cleaning only.
22 Glass Ceramic Cooktop
Explained
on page
3, 10, 33
10
18
15, 22, 23
15, 16
15, 17
15
15, 17
15, 17, 33
4, 35
3, 5, 10–14
9, 12
27, 28, 33
18, 19, 25, 27,
28, 33
4, 18, 19, 25,
27–29, 33
33
27–29, 34
4, 25,
27–29, 34
3, 35
2
3, 36
18, 29, 35
19, 22, 25,
27, 29–31
8, 9, 12, 14
