Start Here
Installing your Microtek XT3300
Unpack your scanner package and check
for major components.
1. Scanner
2. Power adapter
3. Power cord
4. Software CDs/DVDs
5. Hi-Speed USB cable
Important:
Do not remove the yellow stickers from your
scanner until you are told to do so. You must install
software before connecting your scanner.
Always close any open programs and turn off Anti-virus
utilities before installing software.
PC:
A. Place the Microtek Software CD/DVD
into a drive, and follow the on-screen
instructions to install the scanner
driver and software.
B. Restart your computer at the end of
all software installation.
NOTE: If the Microtek Software Installer
screen does not come up automatically,
double-click the following in succession: "My
Computer"; the CD/DVD-ROM icon; then
cdsetup.exe to start the installer program.
Copyright © 2013 Microtek International, Inc. http://www.microtek.com
I49-004547 B, September 2013
Unpack Contents
Install Software
1
5
MAC:
A. Place the Microtek Software CD/DVD
(ScanPotter) into a drive, and double-
click the ScanPotter installer icon to
install ScanPotter.
B. Install the remaining software
components, then restart your computer
at the end of all software installation.
NOTE: After rebooting your Macintosh, the
Microtek software will attempt to locate your
scanner on the system. Since this is your first
install and you have not yet connected the
scanner, simply ignore the message that appears
and proceed to the next step.
1
2
3
4
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Microtek XT3300
Summary of Contents for Microtek XT3300
-
Page 1: Install Software
NOTE: If the Microtek Software Installer NOTE: After rebooting your Macintosh, the screen does not come up automatically, Microtek software will attempt to locate your double-click the following in succession: “My scanner on the system. Since this is your first Computer”;... -
Page 2: Unlock Scanner
Unlock Scanner A. Remove the yellow “Step 3” sticker from your scanner. B. With the scanner power off, tilt the front right corner of the scanner to see the locking switch at the bottom. C. Push the locking switch to the position as indicated in the graphic, with the icon on the lock showing as “Unlocked”. - Page 3 Power switch Customize the Function Buttons The XT3300 is equipped with 3 programmable function buttons (F1, F2, and F3) that can be customized to automate a number of predefined operations, such as scanning to a file, sending an image to your printer, scanning for OCR, etc. Customizing is done through the Save Settings to Function Button command in the ScanWizard DI, refer to the XT3300 User’s Manual for more details.
- Page 4 Position Documents 1. Raise the scanner lid. 2. Place the document to be scanned facing down on the glass surface of the scanner. Center the top of the document along the horizontal ruler on the scanner. 3. Lower the scanner lid. NOTE: To scan a book or thick documents, you may lift the scanner lid out of its hinge sockets.
- Page 5 “Main”) Window expansion Preview image (the button enclosed frame bordered Image type in red) Image correction settings Preview window NOTE: For details on other scanning scenarios applicable to the XT3300, refer to the XT3300 User’s Manual.
- Page 6 9. Click the Scan button to start scanning. NOTE: For more details on using ScanPotter, refer to the ScanPotter Reference Manual in the Microtek Software CD/DVD.
- Page 7 Click the Scan Settings button Scan frame to switch back to the default (enclosed by dotted lines) control panel of ScanPotter Click the Image Settings button to switch to a window where contains a composite display of nine- image-effects (Filter column) and additional image correction tools (Additional Adjustment...
- Page 8 Problems? The LED on the front panel indicates the status of the scanner. On - Ready to scan Green Flashing - Scanning Off - Scanner is off LED indicator First, make sure that you have followed Steps 1 to 4 as described in this guide (unpack, install, unlock, connect).
- Page 9 Finally, select and click the title of the manual you wish to view. Missing Items If your package is missing items, please call the Microtek Customer Service Department. Drivers & Software Upgrades After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download...
