Microtek XT6060 User Manual

Document imaging scanner
Hide thumbs Also See for XT6060:

Advertisement

Quick Links

Download this manual
www.microtek.com
Document Imaging
Scanner
XT6060
User's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the XT6060 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microtek XT6060

Summary of Contents for Microtek XT6060

  • Page 1 Document Imaging Scanner XT6060 User's Manual www.microtek.com...

  • Page 2: Preface

    The contents of this manual have been checked carefully for accuracy, and every effort has been made to ensure that there are no errors. However, Microtek makes no guarantee as to the accuracy of the contents of this document and reserves the right to make changes to the contents without prior warning.

  • Page 3: Fcc Compliance Statement

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. XT6060 User's Manual...

  • Page 4: Safety Precautions

    When you need a repair service, unplug the scanner from the power outlet and consult qualified service personnel. • When replacement parts are required, use replacement parts that are specified by the manufacturer or have the same characteristics as the original parts. XT6060 User's Manual...

  • Page 5: Table Of Contents

    Preface ....................2 FCC Compliance Statement ..............3 Safety Precautions ................4 Knowing about Your Scanner ............. 7 Features of the XT6060 ..............7 Installation Requirements ..............8 Taking a Closer Look ................ 9 Front/Open View ............... 9 Rear View ................10 Initial Setup ..................
  • Page 6 Customizing the Function Buttons ..........34 Care and Cleaning ................36 Cleaning the Scanner Glass Surfaces ..........36 Appendix ..................37 Troubleshooting ................37 Specifications ................38 XT6060 User's Manual...

  • Page 7: Knowing About Your Scanner

    All you need to do is simply press a button and the corresponding function can be carried out. • Large 12“ x 17“ scan bed — The tabloid-size scan bed of the XT6060 lets you easily scan oversized originals, contact sheets, large pieces of art, and mechanical blueprints.

  • Page 8: Installation Requirements

    Color dropout : Red, green and blue colors can be dropped out to allow for clearer and more accurate forms processing with problematic color documents. Installation Requirements In order to use your XT6060, your computer must satisfy the following system requirements: • CD/DVD-ROM drive (for installing software) •...

  • Page 9: Taking A Closer Look

    Indicates the scanner is on or off. READY Indicator (Green) Indicates the status of the scanner. For more details, refer to the “Troubleshooting” section of this manual. Horizontal Ruler Used to measure the width of a scanned document. XT6060 User's Manual...

  • Page 10: Rear View

    Rear View Names of Parts Functions of Parts Hi-Speed USB Port Connects the Hi-Speed USB (USB 2.0) cable to the computer. Power Connector Connects the scanner to the power adapter. Power Switch Turns the scanner on or off. XT6060 User's Manual...

  • Page 11: Initial Setup

    Follow the steps in order for a quick and easy installation process. Step 1: Unpacking Package Contents After unpacking your scanner package, please check for the major components listed below. Power adapter XT6060 scanner Power cord Hi-Speed USB cable Software CDs/DVDs XT6060 User's Manual...

  • Page 12: Step 2: Installing The Software

    After you finish the installation of software, if you found that the installed drivers and software cannot run your product or your computer system properly later, please go to the Microtek Download Service site at ww7.microtek.com.tw/service.php to download and install any updates you may require.

  • Page 13: Step 3: Unlocking The Scanner

    2. Connect the power adapter to the back of the scanner. 3. Plug one end of the power cord into the power adapter, and plug the other end of the power cord into a wall outlet or other power source. XT6060 User's Manual...

  • Page 14: To The Hi-Speed Usb Cable

    6. Turn the power switch at the back of your scanner to “On”, and wait for the lights on the front panel to stop blinking and stay on steady. The system will detect your scanner automatically. Power switch XT6060 User's Manual...

  • Page 15: Positioning Documents

    2. Place the top end of the document towards the front of the scanner, then lower the scanner lid on the scanner glass surface. With the document face down on the scanning glass, align the document against the Horizontal Ruler of the scanner. XT6060 User's Manual...

  • Page 16: Scanning Documents

    Scanning Documents Using ScanWizard DI ScanWizard DI is a scanning software designed by Microtek for document scanning in color, black and white, and grayscale. Its user-friendly interface enables you to easily start the scanning process. Refer to the ScanWizard DI software manual for more details.
  • Page 17 Scan frame (enclosed by dotted lines and labeled with Scanning the tag “Main”) settings Preview image (the enclosed frame bordered in red) Image type Preview window Image correction settings XT6060 User's Manual...

  • Page 18: Scanning Documents With Mixed Contents

    Select Text in the Attribute drop-down menu as your image type for the selected scan frame. If necessary, adjust image quality by using the image correction tools. XT6060 User's Manual...
  • Page 19 The Create Subframe tool lets you create a new scan frame within the enclosed scan frame that is labeled with the tag “Main”. When a new scan frame is generated, the enclosed scan frame is selected in red dotted lines. The newly added subframe is automatically labeled in series (with tag “1”, “2”, etc.). XT6060 User's Manual...

  • Page 20: Scanning Documents With Barcodes On

    If the “Save Barcode as Directory” is unchecked, the program will recognize and use the barcode on the scanned document to name the scanned document. You can append any predefined prefix and/or serial number to the output filename in order to differentiate the documents containing same barcode. XT6060 User's Manual...
  • Page 21 Barcode Frame tool Image correction settings Barcode Separator Barcode number is used as a file directory name Barcode frame (enclosed by dotted Barcode number is used as lines and labeled with a file name the tag “BarCode”) XT6060 User's Manual...

  • Page 22: Scanning A Book In Book Mode

    “Right-hand open” or “Upward open” to scan your book. To select any of the three options, move your cursor toward it and click. The selected option will be highlighted. When done, press the Save button to activate the Book Mode. XT6060 User's Manual...
  • Page 23 If ScanWizard DI is launched as a stand-alone program, the scanned image can be saved after the scan to a file, opened in an image-editing program, or sent to a printer. XT6060 User's Manual...
  • Page 24 “Enable the Book Mode” option is checked at this moment, a pop-up window appears to remind you that these two the book. functions will not work if you activate the Book Mode scanning XT6060 User's Manual...

  • Page 25: Utilizing Scanned Documents

    ScanWizard DI will prompt you a window to ask if you want to place the next page. Click the Continue button to scan or click the Close button to save multiple images as a single file. XT6060 User's Manual...
  • Page 26 XT6060 User's Manual...

  • Page 27: Scanning For Ocr

    Select your preferred language from the “OCR Language” options. The available options are English, German, French, Italian, Spanish, and Chinese. Check the “Send document to application after saving” option, then choose your word processing application from the options. XT6060 User's Manual...
  • Page 28 Click the Continue button to scan or click the Close button to save multiple images as a single file. The saved file can now be opened from your chosen application and is ready to be edited. XT6060 User's Manual...

  • Page 29: Scanning For Pdf

    Note: The scanner also allows you to scan a text document and convert it to an editable PDF file for editing with the Adobe Acrobat writer. Follow the procedures for “Scanning for OCR”, in step 4b, select the “Portable Document Format” as your file-saving format. XT6060 User's Manual...

  • Page 30: Scanning For E-Mail

    “RGB Color” or “Grayscale” is set as your from your chosen e-mail image output type and the PDF is chosen. application to others and is ready With this function, you can control the to be viewed. image quality compression as your desired. XT6060 User's Manual...

  • Page 31: Scanning For Copying

    If the “Fit to Page” option is checked, the “Scaling” setting is disabled. 5. Click the OK button. The document is scanned; when finished, the scanned images are sent to the specified printer. XT6060 User's Manual...

  • Page 32: Activating Auto Scan

    By dragging a slide-bar, you can specify the time interval (among 0 and 6 seconds) to control the auto scan according to your preferences. XT6060 User's Manual...
  • Page 33 The scanner repeat the scanning and file-saving action until you press the “Stop” button to quit the Auto Scan mode. For more details, please refer to a PDF document named “ScanWizard DI Reference Manual” in your Microtek software CD-ROM and see the Auto Scan section. XT6060 User's Manual...

  • Page 34: Customizing The Function Buttons

    Customizing the Function Buttons The XT6060 is equipped with one programmable function button (Scan) that can be customized to automate a number of predefined operations, such as scanning to a file, sending an image to your printer, scanning for OCR, etc. Customizing is done through the “Save Settings to Function Button”...
  • Page 35 OK button. The saved function button settings are restored to the ScanWizard DI control panel. You can then continue to use these settings until you need to specify new settings for the buttons. XT6060 User's Manual...

  • Page 36: Care And Cleaning

    Care and Cleaning To ensure optimal performance from the XT6060, it is important to clean the glass surface of the scanner on a regular basis. Cleaning the Scanner Glass Surface 1. Lift the scanner lid. 2. Then use a soft, non-abrasive and lint-free cloth to gently wipe the glass surface area on the scanner flatbed.

  • Page 37: Appendix

    Uninstall and reinstall the ScanWizard DI or ScanPotter software. 5. Having trouble scanning the documents. Make sure you place the document to be scanned properly on the scanner glass surface. Uninstall and reinstall the ScanWizard DI or ScanPotter software. XT6060 User's Manual...

  • Page 38: Specifications

    Model No. 100V to 240V HAIDER HDAD38W101 Environment Operating temperature: 50° to 105°F (10° to 40°C) Relative humidity: 20% to 85% Important Specifications, software bundles, and accessories are subject to change without notice. Not responsible for typographic errors. XT6060 User's Manual...
