Cooktop Ligh~ight Light
To replace
combination
light, first
disconnect power
at main fuse or
circuit breaker
panel or pull plug.
With smoke and spatter shield (on model so equipped)
in the OUT position, remove screw on right side of
light compartment cover and lower cover until it stops.

Oven Light

To replace your oven light, first
disconnect power at main fuse
or circuit breaker panel or pull
plug.
Remove the top grill by
taking out the 2 screws that hold
it in place.
METAL COOKTOP METAL
FILTER FILTER
LIGHT
SMOKE & SPATTER SHIELD
(On model so equipped)
34
LIGHT BULB ~PLACEMENT
REMOVE-SCREW
Next, remove the single screw
located above door near center
of oven that secures light housing.
Replace burned-out bulb with
a 30-watt incandescent bulb
your GE supplier.
THE EXHAUST FEATU~
The exhaust hood feature on your microwave oven is equipped with
2 metal filters which collect grease. When the fan is operated, air is drawn
up through the filters and is then discharged through the provided venting
to the outside.
Be sure bulbs
to be replaced
are cool before
removing. Break
the adhesive
seal by gently
unscrewing the
bulbs. Replace with 40-watt incandescent bulbs
High intensity 40-watt bulbs (40S 11 N/l ), which are
available in supermarkets and hardware stores,
may also be used for replacements. Raise light
compartment cover and replace screw. Connect
electrical power to microwave oven.
Clean off the grease and dust on
hood surfaces often. Use a solution
of warm water and detergent. About
1 tablespoon of ammonia maybe
added to the water. Take care not to
touch the filters and enamel surfaces
with this solution; ammonia will
darken metal. Wash the smoke
and spatter shield (on model so
equipped) with a solution of warm
water and detergent.
