Displaying Port Operational States; Displaying Port Speeds - Qlogic SANbox2-64 User Manual


6.1.1.2

Displaying Port Operational States

To display the operational state on each port in the faceplate display, open the
View menu and select View Port States.
states and their meanings. The port operational state refers to actual port state
and not the administrative state you may have assigned.
State
On
Ia
Off
Tst
Dn
6.1.1.3

Displaying Port Speeds

To display the speed of each port in the faceplate display, open the View menu
and select View Port Speeds.
State
1Gb
2Gb
59048-01 A
Table 6-2 Port Operational States
Online – port is active and ready to send data.
Inactive – port operational state is offline, but administrative state is
online.
Offline – port is active, can receive signal, but cannot accept a device
login.
Diagnostics – port is in diagnostics mode in preparation for testing
Down – the port is inactive or shut off, not receiving a signal, and can't
be logged in.
Table 6-3
Table 6-3 Port Speeds
1 Gbps transmission speed
2 Gbps transmission speed
Displaying Port Information
Table 6-2 lists the possible operational
Description
lists the possible speeds.
Description
6 – Managing Ports
6-3
