Helmer i.series Operation Manual

I.seriesand horizon series undercounter refrigerator
Hide thumbs Also See for i.series:
Table of Contents

Advertisement

Quick Links

See also: Service Maintenance Manual , Operating Manual
Undercounter Refrigerator Operation Manual
i.Series
and Horizon Series™
®
HELMER SCIENTIFIC
14400 Bergen Boulevard
Noblesville, IN 46060 USA
PH +1.317.773.9073
FAX +1.317.773.9082
USA and Canada 800.743.5637
360128-D/B
Model Group
Blood Bank
iB105 (Version D)
Laboratory/Pharmacy
iLR105 (Version D)
i.Series
Horizon Series
HB105 (Version D)
HLR105 (Version D)
0086
ISO 13485:2003 CERTIFIED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i.series and is the answer not in the manual?

Questions and answers

Related Manuals for Helmer i.series

Summary of Contents for Helmer i.series

  • Page 1 Undercounter Refrigerator Operation Manual i.Series and Horizon Series™ ® Model Group i.Series Horizon Series Blood Bank iB105 (Version D) HB105 (Version D) Laboratory/Pharmacy iLR105 (Version D) HLR105 (Version D) HELMER SCIENTIFIC 14400 Bergen Boulevard Noblesville, IN 46060 USA PH +1.317.773.9073 0086 FAX +1.317.773.9082...
  • Page 2 Document History Revision Date Supersession Revision Description 23 JAN 2013 8187 Initial release. ► Removed all references to mechanical Access Control. ► Added references to magnetic Access Control. 26 NOV 2013* 8934 B supersedes A ► Corrected shipping location of monitoring system backup battery for Horizon Series.

  • Page 3: Table Of Contents

    7 Maintenance Schedule ........... . . 11 Section II: i.Series ®...
  • Page 4 10 Components ............. . 18 10.1 Front and Base .

  • Page 5: Section I: General Information

    , i.C³ , Horizon Series™, and Rel.i™ are registered trademarks or trademarks of ® Helmer, Inc. in the United States of America. Copyright © 2013 Helmer, Inc. All other trademarks and registered trademarks are the property of their respective owners. Helmer, Inc., doing business as (DBA) Helmer Scientific and Helmer.

  • Page 6: Avoiding Injury

    ► Proceed with caution when adding and removing samples from the refrigerator. ► Use supplied power cord only. ► Using the equipment in a manner not specified by Helmer Scientific may impair the protection provided by the equipment. ► Decontaminate parts prior to sending for service or repair. Contact Helmer Scientific or your distributor for decontamination instructions and a Return Authorization Number.

  • Page 7: Specifications

    General Information Specifications iB105 iLR105 HB105 HLR105 Exterior Dimensions Height 33.5” (851 mm) (2,3) Width 24” (610 mm) Depth 28.5” (724 mm) Physical Weight 205 lbs (93 kg) 195 lbs (89 kg) 199 lbs (91 kg) 189 lbs (86 kg) Interior Volume 5 ft³...

  • Page 8: Stacked Undercounter Units

    ► When stacking a refrigerator and freezer (104 and/or 105 models), place the heavier unit on the bottom. ► Do not open multiple, loaded drawers or baskets at the same time. Call Helmer or your distributor for more information on the stacking kit, and for methods to secure both units to the wall and/or the floor. 360128-D/B...

  • Page 9: Compliance

    General Information Compliance Regulatory Compliance This device complies with the requirements of directive 93/42/EEC concerning Medical Devices, as amended by 2007/47/EC. 0086 Sound level is less than 70 dB(A). Emergo Europe Molenstraat 15 2513 BH The Hague, Netherlands WEEE Compliance The WEEE (waste electrical and electronic equipment) symbol (right) indicates compliance with European Union Directive WEEE 2002/96/EC and applicable provisions.

  • Page 10: Placement

    Move refrigerator into place. Lock casters if installed. Ensure refrigerator is level. NOTE Helmer recommends the use of leveling feet (unless casters are installed). Temperature Probes For each probe bottle, use: ► 4 oz. (120 mL) of product simulation solution (10:1 ratio of water to glycerin).

  • Page 11: Install And Change Chart Paper

    General Information 6.5.1 Install and Change Chart Paper Press and hold C button. When stylus begins to move left, release button. The LED flashes to indicate current temperature range. When stylus stops moving, remove chart knob then move knob up and away from chart paper. Place new chart paper on chart recorder. Gently lift stylus and rotate paper so current time line corresponds to time line groove. Hold chart paper and reinstall chart knob.

  • Page 12: Maintenance Schedule

    Temperature Chart Recorder Operation and Service Manual. ► Inspect electrical components and wiring terminals in the  electrical box for discoloration. Contact Helmer Technical Service if any discoloration is found. ► Inspect all wiring for terminals for secure connection. Tighten wiring terminal connections as necessary.
  • Page 13 Access Control lock (if equipped). If the backup battery is not functioning, the optional Access Control lock will not secure the door. ► i.Series: If rechargeable battery has been in service for two years, replace battery. ► Horizon Series: If monitoring system battery has been in service for one year, replace battery.

  • Page 14: Section Ii: I.series ® Models

    Models Section II: i.Series Models ® Operation Initial Start Up Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. Switch AC ON/OFF switch ON. Switch backup battery switch ON. NOTE ► For models equipped with the optional Access Control, the backup battery is switched on with a key switch.

  • Page 15: Normal Operation

    Models Normal Operation The i.C³ Home screen displays temperature and alarm information, and provides icons for reaching other functions of the i.C³. Home screen Home screensaver (touch to return to Home screen) Change Temperature Setpoint Touch + or – on spin box to change value.

  • Page 16: Active Alarms

    Models Active Alarms Home with no alarms. Home with active alarm. Alarm Description High Temperature Chamber temperature reading is above high temperature alarm setpoint Low Temperature Chamber temperature reading is below low temperature alarm setpoint Low Battery Rechargeable battery voltage is low...

  • Page 17: Access Control (Optional)

    Models Access Control (Optional) Allows user-specific secure access to the refrigerator. NOTE ► During a power failure, the optional Access Control lock will remain locked until battery power is depleted or until the backup battery key switch is switched OFF. ► Switching the backup battery key switch OFF will disable the monitoring system.

  • Page 18: Open Refrigerator With Access Control

    Models 8.8.2 Open Refrigerator with Access Control ► Enter a valid PIN using the keypad. i.C³ Icon Reference Guide ® Home Mute Icon Transfer Display Event Log Download Brightness Settings Upload Scroll Arrows i.C³ Applications Light On/Off Access Control...

  • Page 19: Components

    Models Components 10.1 Front and Base Front and base features (iB105 model shown). Label Description Chart recorder (standard on blood bank models, optional on laboratory/pharmacy models) i.C³ control Door handle with lock Caster (optional; leveling feet are standard) USB port...

  • Page 20: Access Control Option

    Models 10.1.1 Access Control Option Access Control door handle and lock (iB105 model shown). Label Description Door handle with lock (includes manual keyed lock) Access Control magnetic lock Access Control override key switch 10.2 Chamber Chamber features (multiple models shown).

  • Page 21: Rear

    Models 10.3 Rear Rear features (iB105 model shown). Label Description Insert for stacking bracket Drain line Compressor Product specification label Power connector Access port Rear panel Remote alarm interface RJ-45 Ethernet port USB port Power cord Condensate evaporator RS-232 COM port (optional)

  • Page 22: Section Iii: Horizon Series™ Models

    Horizon Series™ Models Section III: Horizon Series™ Models Operation 11.1 Initial Start Up Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. Switch AC ON/OFF switch ON. Remove the 9 V battery from the literature box and install it. NOTE ► For models equipped with the optional Access Control, switch the backup battery key switch ON.

  • Page 23: Monitor Offset

    ► Factory-set to match an independent thermometer. ► Varies for each refrigerator. NOTE Control Sensor Offset is factory-preset and should not be changed unless directed by Helmer Technical Service. 11.2.4 Hysteresis ► Allowable temperature variance on each side of the refrigerator setpoint.

  • Page 24: Active Alarms

    Horizon Series™ Models 11.3 Active Alarms The controller displays temperature and alarm information. DOOR ALARM lamp lights Door is open (less than 3 minutes) DOOR ALARM lamp flashes Door has been open 3 minutes or longer * HIGH TEMP lamp flashes Temperature reaches high temperature set point LOW TEMP lamp flashes Temperature reaches low temperature set point “PoFF”...

  • Page 25: Setup

    Horizon Series™ Models 11.6.1 Setup The Access Control keypad was programmed at the factory with a master code (0000). The master code is used to program the keypad and enter user codes. The master code also releases the door lock. NOTE The master code can not be deleted, and should be changed to prevent unauthorized user code setup.

  • Page 26: Components

    Horizon Series™ Models Components 12.1 Front and Base G H I Front and base features (HB105 model shown). Label Description Chart recorder (standard on blood bank models, optional on laboratory/pharmacy models) Horizon Series temperature monitor and control Door handle with lock Leveling foot (casters are optional) Condenser grill shown...

  • Page 27: Access Control Option

    Horizon Series™ Models 12.1.1 Access Control Option Access Control magnetic door lock (HB105 model shown). Label Description Door handle with lock (includes manual keyed lock) Access Control keypad Access Control magnetic lock assembly Access Control override key switch Access Control backup battery (behind battery cover) 12.2 Chamber Chamber features (multiple models shown).

  • Page 28: Rear

    Horizon Series™ Models 12.3 Rear Rear features (HB105 model shown). Label Description Insert for stacking bracket Drain line Compressor Product specification label Power connector Access port Rear panel Remote alarm interface Power cord Condensate evaporator END OF MANUAL 360128-D/B...
  • Page 30 HELMER SCIENTIFIC 14400 Bergen Boulevard Noblesville, IN 46060 USA PH +1.317.773.9073 FAX +1.317.773.9082 www.helmerinc.com...
