ADA Undercounter Refrigerator Operation Manual
i.Series™ and Horizon Series™
HELMER SCIENTIFIC
14400 Bergen Boulevard
Noblesville, IN 46060 USA
PH +1.317.773.9073
FAX +1.317.773.9082
USA and Canada 800.743.5637
360167-D/A
Model Group
Blood Bank
iB104-ADA (Version D)
Laboratory/Pharmacy
iLR104-ADA (Version D) HLR104-ADA (Version D)
i.Series
Horizon Series
HB104-ADA (Version D)
0086
ISO 13485:2003 CERTIFIED
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Helmer i.Series
Summary of Contents for Helmer i.Series
- Page 1 ADA Undercounter Refrigerator Operation Manual i.Series™ and Horizon Series™ Model Group i.Series Horizon Series Blood Bank iB104-ADA (Version D) HB104-ADA (Version D) Laboratory/Pharmacy iLR104-ADA (Version D) HLR104-ADA (Version D) HELMER SCIENTIFIC 14400 Bergen Boulevard Noblesville, IN 46060 USA PH +1.317.773.9073 0086 FAX +1.317.773.9082...
- Page 2 Document History Revision Date Supersession Revision Description 11 FEB 2013 8268 Initial release. * Date submitted for Change Order review. Actual release date may vary. 360167-D/A...
-
Page 3: Table Of Contents
Section II: i.Series™ Models........ - Page 4 10 Components ............. . 15 10.1 Front and Base .
-
Page 5: Section I: General Information
, i.C³ , Horizon Series™, and Rel.i™ are registered trademarks or trademarks of ® Helmer, Inc. in the United States of America. Copyright © 2013 Helmer, Inc. All other trademarks and registered trademarks are the property of their respective owners. Helmer, Inc., doing business as (DBA) Helmer Scientific and Helmer. -
Page 6: General Recommendations
► When stacking a refrigerator and freezer (104 and/or 105 models), place the heavier unit on the bottom. ► Do not open multiple, loaded drawers or baskets at the same time. Call Helmer or your distributor for more information on the stacking kit, and for methods to secure both units to the wall and/or the floor. 4.2 Electrical Specifications Refer to specification label for voltage and power consumption requirements. Voltage tolerance is ±10%. -
Page 7: Dimensions
General Information Dimensions 4.3.1 Weight nOTE The weight may vary slightly depending on installed options. Weights provided are for standard configurations as shown. Model Configuration Weight Family 199 lbs 2 drawers 91 kg 191 lbs 2 shelves 87 kg 193 lbs 2 drawers 88 kg 185 lbs 2 shelves 84 kg... -
Page 8: Regulatory Compliance
Ensure door is closed and casters (if installed) are unlocked. Move refrigerator into place. Lock casters if installed. Ensure refrigerator is level. nOTE Helmer recommends the use of leveling feet. Strain relief for power cord (for refrigerators with casters installed) 360167-D/A... -
Page 9: Temperature Probes
General Information Temperature Probes For each probe bottle, use: ► Approximately 4 oz (120 ml) of product simulation solution (10:1 ratio of water to glycerin). Chart Recorder Chart recorder with paper and battery installed. Label Description Function Left and Right Arrow Adjust settings and stylus position buttons Indicates status of chart recorder in operating mode, or selected... -
Page 10: Install And Change Chart Paper
General Information 6.3.1 Install and Change Chart Paper Press and hold C button. When stylus begins to move left, release button. The LED flashes to indicate current temperature range. When stylus stops moving, remove chart knob then move knob up and away from chart paper. Place new chart paper on chart recorder. Gently lift stylus and rotate paper so current time line corresponds to time line groove. Hold chart paper and reinstall chart knob. -
Page 11: Maintenance Schedule
► If the backup battery does not provide power to the monitoring system during the power failure alarm test, replace the battery. ► i.Series: If rechargeable battery has been in service for 2 years, replace battery. ► Horizon Series: If battery has been in service for 1 year, replace battery. -
Page 12: Section Ii: I.series™ Models
Models Section II: i.Series™ Models Operation Initial Start Up Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. Switch AC ON/OFF switch ON. Switch backup battery switch ON. nOTE The i.C³ monitoring and control system will take approximately 2 minutes to boot up. -
Page 13: Normal Operation
Models normal Operation The i.C³ Home screen displays temperature and alarm information, and provides icons for reaching other functions of the i.C³. Home screen Home screensaver (touch to return to Home screen) Active Alarms Home with no alarms. Home with active alarm. -
Page 14: Light Operation
Models Light Operation Access Control (Optional) Allows user‑specific secure access to the refrigerator. 8.8.1 Setup Configure and manage use‑specific accounts to allow controlled access to the refrigerator. > > > Access Setup ► Enter the supervisor PIN to set up Access Control ► Initial factory supervisor PIN = 5625 nOTE The supervisor PIN can not be deleted, and should be changed to prevent unauthorized user ID setup. -
Page 15: Open Refrigerator With Access Control
Models 8.8.2 Open Refrigerator with Access Control ► Enter a valid PIN using the keypad. i.C³ Icon Reference Guide ® Home Mute Icon Transfer Display Event Log Download Brightness Settings Upload Access Control i.C³ Temperature Access Control Applications Graph... -
Page 16: Components
Models Components 10.1 Front and Base Front and base features (iB104-ADA model shown). Label Description i.C³ control Door handle with lock Base Caster (optional; leveling feet are standard) Chart recorder (standard on blood bank models, optional on laboratory/pharmacy models) -
Page 17: Access Control Option
Models 10.1.1 Access Control Option Access Control door handle and lock (iB104-ADA model shown). Label Description Door handle with lock (includes manual override key) 10.2 Chamber Chamber features (multiple models shown). Label Description Probe bottle Shelf (laboratory/pharmacy models) Roll out basket (optional) -
Page 18: Rear
Models 10.3 Rear Rear features (iB104-ADA model shown). Label Description Insert for stacking bracket Drain line Compressor Product specification label Power connector Access port Rear panel Remote alarm interface RJ-45 Ethernet port USB port Power cord Condensate evaporator RS-232 COM port (optional) -
Page 19: Section Iii: Horizon Series™ Models
Horizon Series™ Models Section III: Horizon Series™ Models Operation 11.1 Initial Start Up Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. Switch AC ON/OFF switch ON. Reverse 9 V backup battery and connect it. nOTE If an alarm condition other than High Temperature occurs, refer to the service manual for troubleshooting. -
Page 20: Hysteresis
Horizon Series™ Models 11.2.4 Hysteresis ► Default setpoint is 2.0 ºC. ► Allowable temperature variance on each side of the refrigerator setpoint. nOTE Hysteresis is factory-preset and should not be changed. 11.2.5 Change a Temperature Alarm Setpoint Flashing Lamp Selected Setting HIGH TEMP and MONITOR High Temp alarm setpoint LOW TEMP and MONITOR... -
Page 21: Mute And Disable Audible Alarms
Horizon Series™ Models 11.4 Mute and Disable Audible Alarms Muting audible alarms does not disable alarm lamps or signals sent through the remote alarm interface. To disable all audible alarms, insert the key in the Alarm Disable switch and turn. 11.5 Light Operation The light switch is located on the monitoring and control panel. -
Page 22: Open Refrigerator With Access Control
Horizon Series™ Models 11.6.4 Open Refrigerator with Access Control ► Enter the user code ► Press # Components 12.1 Front and Base Front and base features (HB104-ADA model shown). Label Description Horizon control (shown with optional Access Control keypad) Door handle with lock Base Leveling foot (casters are optional) Chart recorder (standard on blood bank models, optional on... -
Page 23: Access Control Option
Horizon Series™ Models 12.1.1 Access Control Option Access Control door handle and lock (HB104-ADA model shown). Label Description Door handle with lock (includes manual override key) Access Control keypad (included with Access Control option) 12.2 Chamber Chamber features (multiple models shown). Label Description Probe bottle... -
Page 24: Rear
Horizon Series™ Models 12.3 Rear Rear features (HB104-ADA model shown). Label Description Insert for stacking bracket Drain line Compressor Product specification label Power connector Access port Rear panel Remote alarm interface Power cord Condensate evaporator EnD OF MAnUAL 360167-D/A... - Page 26 HELMER SCIENTIFIC 14400 Bergen Boulevard Noblesville, IN 46060 USA PH +1.317.773.9073 FAX +1.317.773.9082 www.helmerinc.com...
