- Page 1 Freezer Instructions for Use ® i.Series and Horizon Series™ Upright - Undercounter Laboratory i.Series iLF105-GX iLF120-GX iLF125-GX Horizon Series HLF105-GX HLF120-GX HLF125-GX Blood Bank/Plasma Storage i.Series iBF105-GX iBF120-GX iBF125-GX Horizon Series HBF105-GX HBF120-GX HBF125-GX 360416/B...
- Page 2 , Horizon Series™, and Rel.i™ are registered trademarks or trademarks ® of Helmer, Inc. in the United States of America. All other trademarks and registered trademarks are the property of their respective owners. Helmer, Inc., doing business as (DBA) Helmer Scientific and Helmer.
-
Page 3: Table Of Contents
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Contents About this Manual ....................4 Intended Audience . - Page 4 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® 360416/B...
-
Page 5: About This Manual
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Helmer freezers are intended for the storage of blood products and other medical and scientific products. Safety Symbols and Precautions... -
Page 6: Avoiding Injury
♦ The freezer is not considered to be a storage cabinet for flammable or hazardous materials. ♦ Use caution when moving a stacked configuration. REQUIRED: Decontaminate parts prior to sending for service or repair. Contact Helmer or your distributor for decontamination instructions and a Return Authorization Number. -
Page 7: Installation
• Do not open multiple loaded drawers at the same time. • Do not lean on or push down on an open door or extended drawers. Contact Helmer or your distributor for more information regarding the stacking kit and methods to secure both units to the wall and/or floor. -
Page 8: Temperature Probes
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Temperature Probes A probe bottle and container of propylene glycol have been provided with this unit. The propylene glycol is mixed with water to create a solution which, when placed in the probe bottle, simulates the product stored in the freezer. The product simulation solution temperature reflects the product’s temperature during normal operation. -
Page 9: Chart Recorder (If Included)
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Chart Recorder (if included) Note • For complete information, refer to the Temperature Chart Recorder Operation and Service Manual. • If chart recorder has been operating on battery power, the battery should be replaced to ensure the back-up source has proper charge. - Page 10 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Install / Replace Chart Paper Note For accurate temperature reading, ensure the current time is aligned with the time line groove when the chart knob is fully tightened. 1. Press and hold C button. When stylus begins to move left, release button. The LED flashes.
-
Page 11: I.series ® Operation
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® i.Series ® Operation Initial Power-up 1. Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. 2. Switch AC ON/OFF switch ON. -
Page 12: Operation
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Operation Notes • Refer to the i.C User Guide for complete information regarding the i.C User Interface. • The i.C Home screen displays temperature and alarm information, and provides icons to gain access to other functions of the i.C... -
Page 13: Set Alarm Parameters
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Set Alarm Parameters > > Enter the Settings password. Scroll down to select Alarm Settings. Touch minus (-) or plus (+) on spin box to set each alarm parameter. -
Page 14: Active Alarms
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Active Alarms Home screen with active alarm Table 1. Active Alarms Alarm Description Communication Failure 1 Communication lost between i.C display board and control board Configuration file is corrupt or i.C... - Page 15 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Table 2. Application Icon Table Image Name Image Name Image Name Image Name Home Temperature Graph PDF Download Cancel Test Event Log Alarm Test Upload Save Mute Information Logs...
-
Page 16: Min/Max Temperature Monitoring
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Min/Max Temperature Monitoring The Min/Max temperature display provides the highest and lowest Primary Monitor probe temperature reading since the last system reset (power-on event) or manually-initiated reset. Touch the Reset icon to the right of the display to manually reset. -
Page 17: I.series ® Access Control (Optional)
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® i.Series ® Access Control (Optional) Allows user-specific secure access to the freezer. Notes • During a power failure, the optional Access Control lock will remain locked until battery power is depleted or until the back-up battery key switch is switched OFF. -
Page 18: Horizon Series™ Operation
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Horizon Series™ Operation 6.1 Initial Power Up 1. Plug the power cord into a grounded outlet that meets the electrical requirements on the product specification label. 2. Switch AC ON/OFF switch ON. - Page 19 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® View recorded temperature timer Notes • The timer denotes the period of time that has elapsed. It does not display the time at which a minimum or maximum temperature occurred.
-
Page 20: Set Parameter Values
5. Release SET button. The new setting is saved. 6. Press and hold the Up and Down Arrows simultaneously for 3 seconds to exit program mode. Note Contact Helmer Technical Service to set Rail Limit values. Table 3. Parameter Values Parameter... -
Page 21: Active Alarms
This should not be adjusted from the original setting unless directed by Helmer Technical Service. The Upper and Lower Rail Limits help control the refrigeration based on the control probe temperature reading and the set point. These limit values should not be changed from the default setting unless directed by Helmer Technical Service. NOTICE Control Sensor Offset and Rail Limits are factory-preset and should not be changed. -
Page 22: Horizon Series™ Access Control (Optional)
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Horizon Series™ Access Control (Optional) Allows user-specific secure access to the freezer. Notes • During a power failure, the optional Access Control lock will remain locked until battery power is depleted or until the back-up battery key switch is switched OFF. -
Page 23: Product Specifications
Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Product Specifications Operating Standards These units are designed to operate under the following environmental conditions: ♦ Indoor use only ♦ Altitude (maximum): 2000 m ♦ Ambient temperature range: 15 °C to 32 °C ♦... - Page 24 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Table 6. Freezer Specifications Dimensions W x H x D in. (mm) Net Wt. Cu. Ft/ lbs (kg) Model Voltage Code Amps* Liters Cabinet Door Exterior* 115V 60 Hz 24 x 31.9 x 28.4...
-
Page 25: Compliance
• The use of accessories other than those specified for the product by Helmer is not recommended. They may result in increased emissions or decreased immunity of the device. - Page 26 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Electromagnetic Immunity Immunity Test Compliance Level Electromagnetic Environment - Guidance Floors should be wood, concrete or ceramic tile. If floors are Electrostatic discharge ±8 kV contact (ESD) IEC 61000-4-2 ±15 kV air...
- Page 27 Helmer Scientific i.Series and Horizon Series™ Freezer Instructions for Use ® Emergo Europe Helmer Scientific Prinsessegracht 20 EC REP 14400 Bergen Blvd. 2514 AP The Hague Noblesville, Indiana 46060 USA The Netherlands 360416/B...
- Page 28 Helmer Scientific 14400 Bergen Boulevard, Noblesville, IN 46060 USA 360416/B Copyright © 2021 Helmer, Inc.
