Helmer i. series Operation Manual

Undercounter freezer
Hide thumbs Also See for i. series:
Table of Contents

Advertisement

Quick Links

See also: Service Maintenance Manual , Service Manual
Undercounter Freezer

Operation Manual

i.Series™ and Horizon Series™
Plasma Storage Models
• i.Series: iPF105 (Version B)
• Horizon Series: HPF105 (Version B)
Laboratory Models
• i.Series: iLF105 (Version B)
• Horizon Series: HLF105 (Version B)
Model
S/N
0086
ISO 13485:2003 CERTIFIED
360137-1/D
HELMER, INC.
14395 Bergen Boulevard
Noblesville, IN 46060 USA
Phone +1 (317) 773-9073
USA and Canada (800) 743-5637

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i. series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Helmer i. series

Summary of Contents for Helmer i. series

  • Page 1: Operation Manual

    Horizon Series™ Plasma Storage Models • i.Series: iPF105 (Version B) • Horizon Series: HPF105 (Version B) Laboratory Models • i.Series: iLF105 (Version B) • Horizon Series: HLF105 (Version B) Model HELMER, INC. 14395 Bergen Boulevard Noblesville, IN 46060 USA 0086 Phone +1 (317) 773-9073 USA and Canada (800) 743-5637 ISO 13485:2003 CERTIFIED 360137-1/D...

  • Page 2: Table Of Contents

    Contents Section I: General Information ........1 1 About this Manual .
  • Page 3 Undercounter Freezer Operation Manual 10 General Operation ............26 10.1 Power on .

  • Page 4: Section I: General Information

    Section I: General Information Section I: General Information 360137-1/D...
  • Page 5 Undercounter Freezer Operation Manual This page left blank intentionally. 360137-1/D...

  • Page 6: About This Manual

    , i.C³ , Horizon Series™, and Rel.i™ are registered trademarks or trademarks of ™ Helmer, Inc. in the United States of America. Copyright © 2012 Helmer, Inc. All other trademarks and registered trademarks are the property of their respective owners. 360137-1/D...

  • Page 7: Safety

    Decontaminate parts prior to sending for service or repair. Items not CAUTION decontaminated appropriately will not be accepted. Documentation stating contents are not contaminated and are safe to handle must accompany returns. Contact Helmer or your distributor for decontamination instructions and a Return Authorization Number. 360137-1/D...

  • Page 8: Installation

    When stacking a freezer and a refrigerator, always place the freezer on the bottom. Call Helmer or your distributor for more information on the stacking kit, and on optional ways to secure both units to the wall and/or the floor.

  • Page 9: Preparing The Temperature Probe

    Preparing the temperature probe The temperature probe monitors chamber temperature. In addition to using standard probes installed by Helmer, external probes may be introduced through the existing rear port and immersed in the existing probe bottle. For the probe bottle, obtain: ► Approximately 4 oz (120 ml) of product simulation solution.

  • Page 10: Compliance And Energy Conservation

    General Information: Compliance and Energy Conservation Compliance and Energy Conservation Energy conservation and regulatory compliance This device complies with the requirements of directive 93/42/EEC concerning Medical Devices, as amended by 2007/47/EC. This product is certified to applicable UL and CSA standards by a NRTL. 0086 Insulation Type: 2 Pollution Degree: 2 (for use in USA and Canada only)
  • Page 11 Undercounter Freezer Operation Manual This page left blank intentionally. 360137-1/D...

  • Page 12: Section Ii: I.series™ Models

    Section II: i.Series™ Models Section II: i.Series™ Models 360137-1/D...
  • Page 13 Undercounter Freezer Operation Manual This page left blank intentionally. 360137-1/D...

  • Page 14: Components

    i.Series™ Models: Components Components Front and base G H I J K Front and base features (iPF105 model shown). Label Description Label Description i.C³ control Condenser grill Door handle with lock Backup battery switch Base Battery access door Leveling foot (casters are optional) Main power switch Chart recorder (optional on laboratory/ 6 A circuit breakers (230 V models only) pharmacy models) USB port...

  • Page 15: Chamber

    Undercounter Freezer Operation Manual Chamber C D Chamber features (multiple models shown). Label Description Label Description Probe bottle Unit cooler with fan guard Shelf (laboratory/pharmacy models) Chamber label Roll out basket (optional) Standard for adjusting storage components Drawer (plasma storage models) Slide for drawer or basket NOTE Plasma storage models (iPF) feature drawers as the standard storage configuration.

  • Page 16: Rear

    i.Series™ Models: Components Rear iPF105 model shown with detail from various models Label Description Label Description Insert for stacking bracket Rear panel Drain line Remote alarm interface Compressor RJ-45 Ethernet port Product specification label USB port Power connector Power cord Access port Condensate evaporator External drain fan RS-232 COM port (optional) shown 360137-1/D...

  • Page 17: General Operation

    Undercounter Freezer Operation Manual General Operation Power on NOTE Allow unit to come to room temperature before power on. When the power is connected for the first time, the freezer runs frequently to achieve normal operating temperature. This may cause an alarm to sound. When normal operating temperature is reached, the freezer runs normally and automatically clears the alarm.

  • Page 18: Changing Temperature Setpoints

    i.Series™ Models: General Operation Changing temperature setpoints The refrigerator is shipped from the factory with preset temperature setpoints. These setpoints are specific to the refrigerator’s intended use. Instructions for changing the temperature setpoints are outlined within Chapter 11: Alarm Settings, in the i.C³...

  • Page 19: Identifying Active Visual Alarms

    Undercounter Freezer Operation Manual 6.7.3 Defrost status While the freezer is defrosting, the defrost icon appears on the Home screen. Home screen with defrost icon. Identifying active visual alarms If any alarms are active, the Alarm Condition indicator appears, with the type of alarm described below it. If multiple alarms are active, they are sequentially displayed for two seconds each, below the Alarm Condition indicator.

  • Page 20: Maintenance Schedule

    i.Series™ Models: Maintenance Schedule Maintenance Schedule Maintenance tasks should be completed according to the following schedule. Refer to the service manual and the i.C³ User Guide for more detail on the various tasks. NOTE These are recommended minimum requirements. Regulations for your organization or physical conditions at your organization may require maintenance items to be performed more frequently, or only by designated service personnel.

  • Page 21: Technical Specifications

    Undercounter Freezer Operation Manual Technical Specifications Power Input voltage and frequency The requirements for a particular freezer are specified on the product specification label. The voltage tolerance is ±10% of the nominal voltage. Power consumption The power consumption for a particular freezer is specified on the product specification label. Power consumption is measured in full load Amperes.
  • Page 22 i.Series™ Models: Technical Specifications Size All dimensions are for the overall exterior and include items that protrude from the main unit. 24 in Width 610 mm 34 in Height (without casters or leveling feet) 864 mm 28.5 in Depth 724 mm Height notes: With casters, the height of the undercounter freezer is approximately 36 in (920 mm).
  • Page 23 Undercounter Freezer Operation Manual This page left blank intentionally. 360137-1/D...

  • Page 24: Section Iii: Horizon Series™ Models

    Section III: Horizon Series™ Models Section III: Horizon Series™ Models 360137-1/D...
  • Page 25 Undercounter Freezer Operation Manual This page left blank intentionally. 360137-1/D...

  • Page 26: Components

    Horizon Series™ Models: Components Components Front and base F G H I Front and base features (HPF105 model shown). Label Description Label Description Horizon control Monitoring system battery backup Door handle with lock Alarm disable switch Base 6 A circuit breakers (230 V models only) Leveling foot (casters are optional) Main power switch Chart recorder (standard on plasma storage models, optional on laboratory/...

  • Page 27: Chamber

    Undercounter Freezer Operation Manual Chamber C D Chamber features (multiple models shown). Label Description Label Description Probe bottle Unit cooler with fan guard Shelf (laboratory/pharmacy models) Chamber label Roll out basket (optional) Standard for adjusting storage components Drawer (plasma storage models) Slide for drawer or basket NOTE Plasma storage models (HPF) feature drawers as the standard storage configuration.

  • Page 28: Rear

    Horizon Series™ Models: Components Rear Rear features (HPF105 model shown). Label Description Label Description Insert for stacking bracket External drain fan Drain line Rear panel Compressor Remote alarm interface Product specification label RS-232 COM port Power connector Power cord Access port Condensate evaporator 360137-1/D...

  • Page 29: General Operation

    Undercounter Freezer Operation Manual General Operation 10.1 Power on NOTE Allow unit to come to room temperature before power on. When the power is connected for the first time, the freezer runs frequently to achieve normal operating temperature. This may cause an alarm to sound. When normal operating temperature is reached, the freezer runs normally and automatically clears the alarm.

  • Page 30: Changing Temperature Controller Setpoints

    Horizon Series™ Models: General Operation 10.6 Changing temperature controller setpoints The refrigerator is shipped from the factory with preset temperature setpoints. These setpoints are specific to the refrigerator’s intended use. These setpoints may be changed depending on organizational requirements. NOTE The Control Offset and Control Hysteresis are factory preset and should not be changed.

  • Page 31: Identifying Active Visual Alarms

    Undercounter Freezer Operation Manual If this lamp is flashing Then this setting is selected LOW TEMP and MONITOR Low Temp alarm setpoint MONITOR only Monitor Offset CONTROL only Control Offset CONTROL only Control Hysteresis NOTE The control lamp flashes when the Control Offset setting is selected. Press and release the SEL button to select the next setting (Control Hysteresis).

  • Page 32: Maintenance Schedule

    Horizon Series™ Models: Maintenance Schedule Maintenance Schedule Maintenance tasks should be completed according to the following schedule. Refer to the service manual for more detail on the various tasks. NOTE These are recommended minimum requirements. Regulations for your organization or physical conditions at your organization may require maintenance items to be performed more frequently, or only by designated service personnel.

  • Page 33: Technical Specifications

    Undercounter Freezer Operation Manual Technical Specifications Power Input voltage and frequency The requirements for a particular freezer are specified on the product specification label. The voltage tolerance is ±10% of the nominal voltage. Power consumption The power consumption for a particular freezer is specified on the product specification label. Power consumption is measured in full load Amperes.
  • Page 34 Horizon Series™ Models: Technical Specifications Size All dimensions are for the overall exterior and include items that protrude from the main unit. 24 in Width 610 mm 34 in Height (without casters or leveling feet) 864 mm 28.5 in Depth 724 mm Height notes: With casters, the height of the undercounter freezer is approximately 36 in (920 mm).
  • Page 35 HELMER, INC. 14395 Bergen Boulevard Noblesville, IN 46060 USA Phone +1 (317) 773-9073 Fax +1 (317) 773-9082 www.helmerinc.com...

This manual is also suitable for:

Horizon seriesHfl105Ifl105Hpf105Ipf105
