The ultrabright and reliable HDFW26
projector is a perfect fit for any large venue
or event that requires extra brightness to
show clear, crisp images in a luminous
environment.
26,000 lumens, WUXGA, 3chip DLP projector
Reliable and powerful projection
With a light output of 26,000 lumens, the HDFW26 displays superior images
even in venues with lots of ambient light. Thanks to its 3chip DLP technology,
Xenon illumination and highcontrast optical engine, the HDF guarantees crisp
images with rich colors on every occasion. What's more, it is fully ready to
support 3D projection. It has also been equipped with Barco's highend
ImagePRO technology with Athena scaler for flexible scaling.
Wireless control and preview mode
In addition, the versatile HDFW26 offers extended wireless control features
via smart phone or tablet computer. The HDFW26's builtin color LCD screen
provides all the information you need on your projector's status and allows
you to preview your connected sources.
Designed for rental and staging
Building on Barco's experience in the rental and staging market with the
proven FLM family, the HDF has been designed with the road in mind. Its
compact and modular design makes it simple to install and service. Equipped
with an (optional) bottom or top frame, the rugged projector can easily be
rigged as well.
HDFW26
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Barco HDF-W26
Summary of Contents for Barco HDF-W26
- Page 1 Designed for rental and staging Building on Barco’s experience in the rental and staging market with the proven FLM family, the HDF has been designed with the road in mind. Its compact and modular design makes it simple to install and service. Equipped with ...
- Page 2 HDFW26 26,000 lumens, WUXGA, 3chip DLP projector Fast signal distribution Our proprietary BarcoLink technology guarantees swift signal distribution between Barco’s projectors and image processors. With BarcoLink, signals are distributed over a BNC coax cable, which is not only more durable but also enables you to lower your costs. Choose your brightness with HDF Flex The HDFW26 projector is also available with lightondemand option. Thanks to this technology, you can fully tune the light output of the projector to your event: it can be programmed to a light output of 18,000 lumens up to 26,000 lumens in 2,000 incremental steps. In this way, rental companies have more flexibility to offer their customers the light output they want.
- Page 3 Technical specifications HDFW26 Projector type WUXGA 3chip DLP digital projector Technology 0.96" DMD™ x3 Resolution 1,920 x 1,200 Brightness 26,000 center lumens / 23,000 ANSI lumens Contrast ratio 1,900:1 (standard) / 2,400:1 (high contrast mode) Brightness uniformity Aspect Ratio 16:10 ScenergiX Horizontal and vertical edge blending Lens type TLD+ Lenses 0.73:1 ; 1.2:1 ; 1.251.6:1 ; 1.52.0:1 ; 2.02.8:1 ; 2.84.5:1 ; 4.57.5:1 ; 7.511.5:1 Optical lens shift Vertical: 10% to +110% / Horizontal: +/30% (on zoom lenses memorised) Color correction Lamps 3.8 kW xenon Lamp lifetime 750 Hrs Transport with lamp Lamp house, quick replace Customer bulb replace Lamp warranty (field replace/ factory replace) 90 days, 500 hours / pro rata 500 hours Sealed DLP™ core Standard Optical dowser Standard Pictureinpicture Two sources simultaneously Orientation table ceiling side (portrait) vertical Others can be controlled by DMX 512 console, warping...
- Page 4 Technical specifications HDFW26 Shipping Dimensions (LxWxH)1,200 x 980 x 760 mm / 47.24 x 38.58 x 29.92 inches Shipping Weight from Factory 151kg (333lbs) Standard accessories Power cord; wireless/XLR wired rugged remote control, bottom rigging kit/clamps Certifications Compliant with UL609501 and EN609501complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A, RoHS Warranty 2 years standard, extendable up to 5 years Generated on: 04 Jan 2014 Technical specifications are subject to change without prior notice. Please check www.barco.com for the latest information.
