- Page 1 KOBE Brand Range Hood Model No. RA3830SQD RA3836SQD RA-038 SERIES – 5” HEIGHT “RECIRCULATING HOOD” INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS Important Safety Instructions………………………………………………………………. Components of Package…………………………………………………………………… Installation…………………………………………………………………………………… Under the Cabinet Installation………………………………..……..…………………. Stand Alone Installation………………………………………………………………… Operating Instructions.…………………………………...………………………………… Maintenance…………………………………………………………………………………. Specifications…………………………………………………….……..…………………... Measurements & Diagrams…………………………………………………………...…… Parts List…………………………………………………………………..…………………. Circuit Diagram………………………………………………………………...……………. Disclaimer……………………………………………………………………………………. Warranty…………………………………………………………………...………………… Product Registration………………………………………………………...……………… - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING - ALL WIRING MUST BE DONE BY A PROFESSIONAL AND IN ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES. -
Page 3: Important Safety Instructions
KOBE RANG E HOODS authorized agents. Any repair carried out without the supervision of KOBE RANGE HOODS authorized agents will automatically void the warranty. - Page 4 What to Do In The Event Of a Range Top Grease Fire SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
(Must keep all material for returns or refunds) Range Hood Box Duct Cover Box (Sold Separately) {A} KOBE Range Hood {F} KOBE Duct Cover (Model No. RA1020DC) {B} Warranty Registration Card {G} Screws Package {C} Instructions Manual {H} Duct Cover-Mounting Bracket... -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation Calculate the length of the installation, before installing the hood. (All calculation is measure in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top... -
Page 7: Under The Cabinet Installation
UNDER THE CABINET INSTALLATION SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING, OR SERVICING. Preparation before Installation - Temporarily wire the hood to test for proper operation before installing. - Peel protective film off the hood (if any). - Page 8 Draw electrical wires through cabinet access opening. Place screws (not provided) into the exact center of each knockout hole. Make sure all screws are in place before tightening screws. CAUTION: MAKE SURE THE HOOD IS SECURE BEFORE RELEASING. Connect the electrical wires. Refer to “Wiring to Power Supply.” If necessary to hide the electrical wire connections, push wires back into the wiring box.
-
Page 9: Stand Alone Installation
STAND ALONE INSTALLATION ***This installation only applies with the purchase of an optional duct cover (Model No. RA1020DC). SAFETY WARNING HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF IT IS NECESSARY TO REMOVE ANY PARTS FOR INSTALLING, CLEANING OR SERVICING. - Page 10 Mounting Screws Figure 7 Figure 8 Align hood-mounting bracket to the two screws on the wall and hook hood into place. Tighten screws to secure hood to the wall. CAUTION: MAKE SURE THE HOOD IS SECURE BEFORE RELEASING. Duct Cover Installation Mark the position of the duct cover-mounting bracket.
- Page 11 Attach Together Figure 11 10. Fasten outer duct cover to plastic plate on the hood with four (4x8 mm) screws (provided). Wiring to Power Supply SAFETY WARNING RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY SPECIALIZED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL AND LOCAL ELECTRICAL CODES.
-
Page 12: Operating Instructions
OPERATING INSTRUCTIONS This KOBE hood is equipped with four electronic controls with a 10-second standby startup & 30-second delay shutoff, two powerful centrifugal turbine impellers with charcoal filter set, and two bright 12-volt 20-watt halogen lights. The four button controls are Light Control, Speed Control A (cycles through Low, Medium, High, QuietMode™), Speed Control B (cycles through Low, QuietMode™, High, Medium) and... -
Page 13: Maintenance
MAINTENANCE CAUTION: NEVER PUT YOUR HAND INTO THE AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. For the optimal level of operation, clean the range hood surface, charcoal filter unit, and oil containers regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. - Page 14 To Replace Light Bulb CAUTION: HALOGEN LIGHT UNIT MAY BE HOT! WAIT UNTIL UNIT IS COOL. 1) Make sure all control switches are off, and range hood is unplugged. 2) Use a flat head screwdriver to pop out the protective covering as shown on Figure 13. 3) Gently pull out the defective light bulb and discard.
-
Page 15: Specifications
10-Second Standby Startup 30-Second Delay Shutoff HALOGEN LIGHT 12V 20W x 2 HOOD DIMENSION (RA3830SQD) 29-3/4” x 20-1/2” x 5-1/8” (W x D x H) (RA3836SQD) 35-1/4” x 20-1/2” x 5-1/8” OPTIONAL ACCESSORIES 1) Two-Piece Adjustable Duct Cover (W x D x H) (RA1020DC) 10-5/8”... -
Page 16: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All inch measurements are converted from millimeter. Inch measurements are estimated. ***All measurements in ( ) are millimeters. - FOR UNDER THE CABINET - 30” = Knockout Holes “A” 36” = Knockout Holes “A” & “B” - FOR STAND ALONE (WITH OPTIONAL DUCT COVER) - ***Hood-Mounting Bracket ***Duct Cover-Mounting Bracket... -
Page 17: Parts List
PARTS LIST MODEL NO.: RA3830SQD RA3836SQD DESCRIPTION MODEL /SIZE PART NO. Hood Casing RA3830SQD 10-03300-F RA3836SQD 10-03360-F Air Chamber Air Chamber (Top) C1-0102-0770F Air Chamber (Side) C1-0101-0770F Air Chamber (Opening) C1-0241-0770FA Motor (Right) C1-0301-0120-08A Motor (Left) C1-0301-0120-07A Impeller (Right) C1-0251-0092-02... - Page 18 MODEL NO.: RA3830SQD RA3836SQD...
-
Page 19: Circuit Diagram
CIRCUIT DIAGRAM MODEL NO.: RA3830SQD RA3836SQD... -
Page 20: Disclaimer
2. PLEASE INSPECT CONTENTS OF PACKAGE (S) CAREFULLY UPON RECEIVING! We must be notified in writing of any damages and/or missing parts within the allocated days upon receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit. -
Page 21: Warranty
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods, Inc. warrants all products manufactured or supplied by it to be free from defects in workmanship and materials. Its obligations pursuant to this warranty are limited to a period of two years from the date of purchase and to the repair or replacement at its option and subject to the terms and conditions stated below, of any component part, which its examination shall disclose to be so defective. - Page 22 KOBE Range Hoods Agent as applicable, for any traveling expenses and any costs of transporting the...
-
Page 23: Product Registration
KOBE Range Hoods Agent or KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection.
