Summary of Contents for Barco 6300
- Page 1 BARCO PROJECTION SYSTEMS GRAPHICS 6300 R9001440 OWNER'S MANUAL Date : Rev. : Art. No. : 21112000 R5975879...
- Page 2 Federal communication commission (FCC statement) The use of shielded cables is required to comply within the limits of Part15 of FCC rules and EN55022. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
-
Page 3: Table Of Contents
Source numbers 81 - 86 ............. C-2 File Service ................. 9-2 Load File ..................9-2 Edit File ..................9-3 Delete ..................9-5 Rename ..................9-5 Copy ................... 9-5 File Options ................. 9-6 Picture Tuning ................9-6 CTI ON/OFF ................9-6 5975879 BARCOGRAPHICS 6300 21112000... -
Page 4: Unpacking And Dimensions
Unpacking and Dimensions UNPACKING AND DIMENSIONS Unpacking Pull To open 3 7 9 Projector dimensions 371.2 53.5 202.4 53.5 29.6 82.7 211.4 169.5 187.2 139.6 148.9 380.6 152.6 152.6 526.8 5975879 BARCOGRAPHICS 6300 29022000... -
Page 5: Battery Installation In The Rcu
RCU, contact a BARCO service center. If it is necessary to program the projector address into the RCU, see chapter 'Controlling'. 2. projector address has to be reprogrammed everytime the battery is changed, the RCU will always switch to the common address. 5975879 BARCOGRAPHICS 6300 29022000... -
Page 6: Installation Guidelines
Installation Guidelines INSTALLATION GUIDELINES Installation Guidelines * Environment * Environment condition check clean air well * What about ambient light ? -
Page 7: Which Screen Type
Installation Guidelines * Which screen type? Screen width For more information about screens, contact your local screen supplier. * What image size? How big should the image be? * Where to install the projector? Definitions of the Abbreviation on drawings Inputs and computer video format input compatibility : Lens type selection. -
Page 8: How To Install A Projection Lens
Installation Guidelines CD = B - A Projector SIDE VIEW SIDE VIEW CD = B - A Screen Optical axis projection lens Screen Projector A’ Optical axis projection lens Floor Floor Screen Screen TOP VIEW TOP VIEW Floor Floor BACK VIEW BACK VIEW * How to install a projection lens? - Page 9 Installation Guidelines...
-
Page 10: Location And Functions Of Control
Location and Functions of Control LOCATION AND FUNCTIONS OF CONTROL Front Panel Terminology Source & Power Connections S-V IDE O T RIG R S232 IN R S232 O UT C OM M. PO R T VID EO IEE E 1394 M OU SE M ON ITO R A UD IO IN... -
Page 11: Communication Connections
Location and Functions of Control Communication Connections 8 9 10 C OMM. PO RT VIDE O S-VIDE O S DI IEEE 139 4 TRIG MOUSE R S2 32 IN RS2 32 O UT MONITOR A UD IO IN AUDIO IN AUD IO IN H /C COMPU TER... -
Page 12: Remote Control
Location and Functions of Control b. Remote control EXIT ENTER PAUSE TEXT PHASE SHARPN EXIT TINT STANDBY COLOR ENTER BRIGHTN TEXT PAUSE CONTR SHARPN TINT BRIGHTN TREBLE BALANCE PHASE CONTRAST COLOR BASS Attention : Switching to Stand-by. When the projector is running and you want to go to stand-by, press the stand-by key for 2 seconds until the message 'Saving data, please wait' is displayed. - Page 13 Location and Functions of Control...
-
Page 14: Installation Set Up
Installation Set Up INSTALLATION SET UP Configuration Rear/Ceiling Front/Ceiling Rear/Table Front/Table é ê é ê é ê ADJUSTMENT MODE Select a path from below : RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with then <ENTER> INSTALLATION <EXIT> to return. INPUT SLOTS 800 PERIPHERAL CONFIGURATION OSD COLOR... -
Page 15: Connections
Connections CONNECTIONS Power connection AC Power (mains) cord connection S -V IDE O I EEE 1394 TRIG M OUSE RS2 32 IN RS23 2 O UT C OMM. PO RT V ID EO S DI S DO MO NITO R C OMPUTER AUDIO I N AUDIO I N... -
Page 16: Lamp Run Time
Connections Lamp Run Time Lamp run time is 750 hours. Operating the lamp longer than 750 hours may damage the Remaining Lamp run time projector. Please replace the lamp. 20 h WARNING Lamp Run Time Warning Using a lamp for more than 750 hours is dangerous as the lamp could explode. -
Page 17: 5-Cable Input Slot (Slot 1)
Connections 5-cable Input Slot (slot 1) TRIG VIDEO S-VIDEO S DI IEE E 1394 MONITOR C OM PUTER ADJUSTMENT MODE é ê Installation é ê INSTALLATION é ê INSTALLATION INPUT SLOTS INPUT SLOTS... -
Page 18: Computer Input/Monitor Output
Connections Computer input/Monitor output S-V IDEO TRIG RS232 IN RS232 O UT COM M. PORT VIDEO IEEE 1394 M OUSE M ONITO R COM PUTER AUDIO IN AUDIO IN AUDIO IN AUDIO IN Video Input TRIG RS232 IN R S232 OUT C OM M. -
Page 19: S-Video Input
Connections S-Video Input T RIG RS232 IN RS232 O UT COM M. PO RT VIDEO S-VIDEO IEEE 1394 M OUSE MONITO R COM PUTER AUDIO IN AUDIO IN AUDIO IN AUDIO IN A, B or C Lum a/Chroma VCR S-VHS Serial Digital Input / Serial Digital Output S-VIDEO TRIG... -
Page 20: Ieee 1394 Input
Connections Note : When a RCVDS05 is connected to the projector, the SDI input is available by keying in 85 on the RCU. IEEE 1394 Input Communication Connections RS232 in / RS232 out S-VIDEO IEEE 1394 TRIG MOU SE R S232 IN RS232 OUT C OMM. -
Page 21: Communication Port For Communication With Peripherals
Connections Communication port for communication with peripherals Audio Connections é ê é ê é ê ç è... -
Page 22: Controlling
COM M. P O R T H/ C COM PUT E R M ONI TOR A UDIO I N AUD IO IN A UDIO I N AUDI O IN ƒ ƒ ƒ ƒ 3$86( 7(;7 3$86( 7 (;7 5975879 BARCOGRAPHICS 6300 22022000... -
Page 23: Projector Address
How to control the projector or projectors. c. Using the RCU. Common Address Displaying a Projector Address. ADDRESS PROJECTOR ADDRESS How to Program an Address into the RCU? ADDRESS Picture controls with direct access. Brightness Control 'brightness' BRIGHTNESS Contrast Control Color Saturation 5975879 BARCOGRAPHICS 6300 22022000... -
Page 24: Sound Controls With Direct Access
Controlling Tint Control Sharpness Control. Phase Control Freez key Sound controls with direct access. Volume Control Bass Control Treble Control Balance Control The Pause key. 5975879 BARCOGRAPHICS 6300 22022000... -
Page 25: The Selection Key
Controlling The Selection key. é ê ç è EXIT Zoom/Focus Change with é,ê,ç,è ENTER <ENTER> to Shift <EXIT> to return é ê ç è EXIT 5975879 BARCOGRAPHICS 6300 22022000... -
Page 26: Start Up Of The Adjustment Mode
Start up of the Adjustment Mode START UP OF THE ADJUSTMENT MODE Adjustment Mode ADJUST ENTER ADJUSTMENT MODE Select a path from below : AUTO IMAGE RANDOM ACCESS INSTALLATION SERVICE ENTER EXIT Source 01 Select with then <ENTER> ADJUST <EXIT> to return. Auto Image Installation Random Access... -
Page 27: Auto Image Adjustment
Auto Image Adjust AUTO IMAGE ADJUSTMENT Auto Image Adjustment é ê ENTER ADJUSTMENT MODE Select a path from below : AUTO IMAGE RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with then <ENTER> <EXIT> to return. Adjust ADJUSTMENT MODE Select a path from below : AUTO IMAGE RANDOM ACCESS é... -
Page 28: Random Access Adjustment Mode
Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE ADJUSTMENT MODE é ê ENTER... -
Page 29: File Service
Random Access Adjustment Mode RANDOM ACCESS é ê ADJUSTMENT MODE ENTER EXIT ADJUST FILE SERVICE é ê FILE SERVICE ENTER LOAD FILE è ç ENTER é ê ENTER CONFIRM LOAD FILE ENTER EXIT... -
Page 30: Edit File
Random Access Adjustment Mode FILE SERVICE EDIT é ê ENTER EDIT FILE ENTER EDIT FILE xga.s30 é ê ENTER ENTER è ç é ê ENTER è ç (Caution : Do not adjust these settings on an active file, they are used to identify the input source file.) - Page 31 Random Access Adjustment Mode Read AMDS Options EDIT FILE OPTIONS ENTER è ç xam ple for clam p position [trailing] è ç Sync pulse ENTER Clamp pulse Clamp width ENTER Clamp delay ENTER EXIT CONFIRM ENTER EXIT EDIT FILE...
-
Page 32: Delete
Random Access Adjustment Mode é ê FILE SERVICE ENTER é ê ENTER RENAME FILE ç è é ê RENAME FILE ENTER EXIT FILE SERVICE é ê ENTER é ê ENTER COPY FILE ç è COPY FILE é ê ENTER EXIT FILE SERVICE é... -
Page 33: File Options
Random Access Adjustment Mode ENTER CONFIRM EXIT DELETE FILE é ê ENTER FILE SERVICE FILE OPTIONS é ê ENTER RANDOM ACCESS ADJUSTMENT MODE PICTURE TUNING PICTURE TUNING CTI [ON] é ê ENTER... -
Page 34: Color Temperature
Random Access Adjustment Mode é ê PICTURE TUNING ENTER COLOR TEMPARATURE COLOR TEMPERATURE é ê ENTER é ê ç è GAIN RED PICTURE TUNING é ê GAMMA ENTER ç è EXIT GAMMA = 2.2 PICTURE TUNING DECODING [EBU] é ê ENTER EXIT... -
Page 35: Input Balance
Random Access Adjustment Mode PICTURE TUNING é ê DYNAMIC COLOR DEPTH ENTER ç è EXIT DYNAMIC COLOR DEPTH PICTURE TUNING é ê ENTER ç è NOISE REDUCTION EXIT NOISE REDUCTION PICTURE TUNING INPUT BALANCE é ê INPUT BALANCE ENTER é ê... -
Page 36: Audio Tuning
Random Access Adjustment Mode é ê ENTER RANDOM ACCESS ADJUSTMENT MODE AUDIO TUNING AUDIO TUNING é ê AUDIO TUNING ENTER MUTE [OFF] AUDIO TUNING é ê ENTER FADE... -
Page 37: Mode [Stereo]/[Mono]
Random Access Adjustment Mode AUDIO TUNING é ê ENTER MODE [STEREO] FADE é ê AUDIO TUNING ENTER ç è ENTER é ê ENTER RANDOM ACCESS ADJUSTMENT MODE GEOMETRY ENTER ENTER... - Page 38 Random Access Adjustment Mode GEOMETRY é ê ENTER é ê ç è GEOMETRY Fixed sides Horizontal size é ê adjustment ENTER é ê ç è Vertical size adjustment Example for table mount configuration GEOMETRY é ê ENTER ç è ç è...
-
Page 39: Blanking
Random Access Adjustment Mode GEOMETRY é ê ENTER BLANKING Top blanking Right blanking Left blanking Bottom blanking Adjustment of the blanking on the top of the image BLANKING Adjustment of the blanking on the bottom of the image Correct by pushing the cursor key up or down Adjustment of the blanking on the left side Adjustment of the blanking on the right side Correct by pushing the cursor key to the right or to the left... -
Page 40: Aspect Ratio [4:3]/[16:9]
Random Access Adjustment Mode GEOMETRY é ê ENTER ASPECT RATIO [4:3] é ê GEOMETRY ENTER OPTIONS GEOMETRY OPTIONS ENTER EXIT... -
Page 41: Installation Mode
1. RGB-SS [CV or HS&VS] 2. RGB-SS [CV or HS&VS] x 3. VIDEO 4. S-VIDEO The indication in the source description can be : 5. DIGITAL INPUT 6. IEEE 1394 Select with <ENTER> to toggle <EXIT> to return. 10-1 5975879 BARCOGRAPHICS 6300 14072000... -
Page 42: No Signal
Zoom with éorê EXIT Focus with çorè ENTER <ENTER> to Shift <EXIT> to return ENTER é ê ç è EXIT Lens Adjustment Shift Horizontal with çorè Vertical with éorê <ENTER> to Zoom/Focus <EXIT> to return 10-2 5975879 BARCOGRAPHICS 6300 14072000... -
Page 43: Text Box Position
NO SIGNAL LENS TEXT BOX POSITION QUICK ACCESS KEYS ENTER START UP MODE more ... Select with then <ENTER> <EXIT> to return. START UP MODE IDENTIFICATION : [ON] Select with then <ENTER> <EXIT> to return. 10-3 5975879 BARCOGRAPHICS 6300 14072000... -
Page 44: Peripheral
800 PERIPHERALS CONFIGURATION ENTER OSD COLOR INTERNAL PATTERNS SWITCHING MODE é ê more ... ENTER Select with then <ENTER> <EXIT> to return. OSD COLOR HIGHLIGHTED ITEM GREEN YELLOW Select with then <ENTER> <EXIT> to return. 10-4 5975879 BARCOGRAPHICS 6300 14072000... -
Page 45: Internal Patterns
Switching Mode INSTALLATION 800 PERIPHERALS CONFIGURATION OSD COLOR é ê INTERNAL PATTERNS SWITCHING MODE ENTER more ... Select with then <ENTER> <EXIT> to return. SWITCHING MODE SWITCHING : [BLANKING] Select with then <ENTER> <EXIT> to return. 10-5 5975879 BARCOGRAPHICS 6300 14072000... -
Page 46: Service Mode
<EXIT> to return <EXIT> to return. then <ENTER> <EXIT> to return. LAMP RUNTIME HISTORY DIMMING Serial No Runtime ----------------------------------------------------- > 0111121 600 h 0110031 990 h 0110010 1000 h 0000000 0000000 0000000 ----------------------------------------------------- <EXIT> to return 11-1 5975879 BARCOGRAPHICS 6300 14072000... -
Page 47: Identification
CHANGE BAUDRATE PC RESET LAMP RUNTIME LAMP RUNTINE HISTORY - projector address DIMMING MORE... Select with then <ENTER> <EXIT> to return. type software version Proj. Address Installation Baud rate Projector Run Time Projector Serial number 11-2 5975879 BARCOGRAPHICS 6300 14072000... -
Page 48: Change Password
Select with then <ENTER> <EXIT> to return. é ê CHANGE PROJ. ADDRESS Projector address 001 Common address 0 ç è Select with é ê Reprogram with or numeric keys <ENTER> to confirm <EXIT> to return 11-3 5975879 BARCOGRAPHICS 6300 14072000... -
Page 49: Common Address
MORE... Select with then <ENTER> LAMP RUNTIME HISTORY <EXIT> to return. Serial No Runtime ----------------------------------------------------- > 0111121 600 h 0110031 980 h 0110010 1000 h 0000000 0000000 0000000 ----------------------------------------------------- <ENTER> for detail <EXIT> to return 11-4 5975879 BARCOGRAPHICS 6300 14072000... -
Page 50: Dimming
Panel Adjustments is reserved to qualified service personnel. then <ENTER> <EXIT> to return. If you are not qualified, press EXIT to cancel the panel adjustments. PANEL ADJUSTMENTS is reserved to qualified service personnel <ENTER> to accept <EXIT> to return. 11-5 5975879 BARCOGRAPHICS 6300 14072000... -
Page 51: Uniformity
74H # # # LAMP DRIVER 78H # # # LCD DRIVER C0H # # # LCD DRIVER C4H # # # LCD DRIVER C8H # # # LCD DRIVER CCH # # # <EXIT> TO RETURN 11-6 5975879 BARCOGRAPHICS 6300 14072000... -
Page 52: Standard Source Set Up Files
1152 VIDEO525 1302 X 239I 29,970 15,734 32,207 1302 1024 VIDEO625 1024 X 278I 25,000 15,625 31,984 1310 1024 PAM500 640 X 400 60,000 26,400 22,810 864 PAM800 1120 X 375I 44,936 36,443 50,000 1372 1120 5975879 BARCOGRAPHICS 6300 181298... -
Page 53: Standard Source Set Up Files
71,955 58,140 80,000 1376 1024 XGA_75 1024 X 768 75,781 61,080 86,000 1408 1024 XGA75_GS 1024 X 768 74,534 59,701 79,284 1328 1024 XGA_85 1024X768 85,000 68,680 94,500 1376 1024 XGA_100 1024X768 100,000 80,800 100,000 1368 1024 5975879 BARCOGRAPHICS 6300 181298... -
Page 54: Lenses
Lenses LENSES Lens Cleaning Procedure 5975879 BARCOGRAPHICS 6300 14072000... -
Page 55: Lenses
Lenses Lenses Lens formulas to calculate the projector distance. Lens program to calculate the projector distance is available on the BARCO webside : http://www.barco.com/projecti/cusserv/index.htm 5975879 BARCOGRAPHICS 6300 14072000... -
Page 56: Source Numbers 81 - 86 And 91 - 96
Source Numbers 80 - 89 and 90 - 99 SOURCE NUMBERS 81 - 86 AND 91 - 96 Projector without any 800 peripheral connected. Projector with a 800 peripheral connected. Source numbers 91 - 99. - Page 57 Source Numbers 80 - 89 and 90 - 99 Source numbers 81 - 86...
