Do not use this equipment before reading this manual!
740
Model Number:
High Rider Basic
High Rider Loaded
Low Rider Basic
Low Rider Loaded
Printed in the U. S. A.
ix
Airless Sprayer
800- 1030
800-1035
800- 1040
800- 1045
Owner's Manual
Digital
NOTE: This manual
contains important
warnings and
instructions. Please
read and retain for
reference.
X-Lock Theft Deterrent System
Security Code
— — — —
_ _ _ _ _ _ _ _ _ _
Serial #
0707 © 2006 Titan Tool Inc. All rights reserved. Form No. 313-2612B
For professional use only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 740ix and is the answer not in the manual?

Questions and answers

Related Manuals for Titan 740ix

Summary of Contents for Titan 740ix

  • Page 1 Low Rider Basic 800- 1040 Low Rider Loaded 800- 1045 _ _ _ _ _ _ _ _ _ _ Serial # 0707 © 2006 Titan Tool Inc. All rights reserved. Form No. 313-2612B Printed in the U. S. A.

  • Page 2: Safety Precautions

    Consultation with a plastic surgeon or • Use lowest possible pressure to flush equipment. reconstructive hand surgeon may be advisable. • Do not spray onto pump assembly. © Titan Tool Inc. All rights reserved.
  • Page 3 IMPORTANT: When the sprayer is used with a generator away from the equipment at all times. or uncontrolled line voltage, the use of Titan’s “Line Surge Protector” (P/N 800-935) is recommended. • Do not overreach or stand on an unstable support. Keep effective footing and balance at all times.

  • Page 4: Table Of Contents

    Read and understand the warnings in the Safety Precautions section at 7. Turn off the sprayer by moving the ON/OFF switch to the the front of this manual before operating this OFF position. equipment. © Titan Tool Inc. All rights reserved.

  • Page 5: Preparing To Paint

    Indicator Solid Green (Bar) including servicing or adjusting any part of the 1901-3300 PSI spray system, changing or cleaning spray tips, or Motor Running preparing for cleanup. Indicator Motor Running Max PSI (Bar) © Titan Tool Inc. All rights reserved.

  • Page 6: Xact Digital Control System Operation (If Equipped)

    SER # XXXXXXXXXX To select the Unit Serial # PRESS 1 FOR MENU screen, press the #4 key. © Titan Tool Inc. All rights reserved.

  • Page 7: Pressure Relief Procedure

    Main Screen. If the new code is re-entered incorrectly, the display will return © Titan Tool Inc. All rights reserved.

  • Page 8: Spraying

    Shrubs next to houses should be tied back and covered with a canvas cloth. The cloth should be removed as soon as possible. Titan gun extensions are extremely helpful in these situations. Nearby objects such as automobiles, outdoor furniture, etc.

  • Page 9: Cleanup

    Max PSI (Bar) ON/OFF switch to the ON position. 4. If you have any further questions concerning your TITAN 8. Allow the solvent to circulate through the unit and flush the Airless Sprayer, call TITAN: paint out of the return hose into the metal waste container.

  • Page 10: Replacing The Filters

    Replacing the Filters Electrostatic discharge (ESD) potential could Pump Filter cause damage to electronic control. Use Titan 1. Loosen and remove the filter housing by hand. ESD wrist strap P/N 700-1037 or equivalent when 2. Slip the filter off of the filter support spring.

  • Page 11: Replacing The Gears

    Assembly Pump Front Control Panel Housing Cover Motor Armature Gear T-Slot Front Crankshaft/Gear Cover Assembly Screw Pump Transducer Block Thrust Washer Assembly 2nd Stage Gear Assembly Gear Box Housing Pump Block Mounting Screw © Titan Tool Inc. All rights reserved.

  • Page 12: Replacing The Prime/Spray Valve

    Replace if they are worn or damaged. 9. Reassemble the valves by reversing the steps above. NOTE: During reassembly, make sure the o-ring between the pump block and foot valve housing is lubricated with grease and in position. © Titan Tool Inc. All rights reserved.
  • Page 13 15. Inspect the piston rod for wear and replace if necessary. NOTE: Coat the piston insertion tool and the piston rod with grease before inserting them into the pump block. © Titan Tool Inc. All rights reserved.

  • Page 14: Troubleshooting

    4. Faulty or loose wiring. 4. Inspect or take to a Titan authorized service center. 5. Excessive motor temperature. 5. Allow motor to cool.

  • Page 15: Xact Digital Control System Error Messages

    Xact Digital sprayer. Once a problem occurs and the error message Control System has risen too high. Take the sprayer to a Titan appears, the sprayer will shut down. authorized service center for repair.

  • Page 16: Français

    • Se servir de la pression la plus basse possible pour vidanger s’avérer nécessaire de consulter un plasticien ou un spécialiste l’appareil. en chirurgie reconstructive de la main. • Ne pas pulvériser de produit sur la pompe. © Titan Tool Inc. Tous droits réservés. Français...
  • Page 17 électrique de la prise avant de travailler sur l’équipement. • N’utilisez pas le tuyau pour tirer ou soulever l’équipement. • Ne pas soulever par la poignée de chariot en chargeant ou en déchargeant. © Titan Tool Inc. Tous droits réservés. Français...

  • Page 18: Español

    Puede ser • No rocíe el ensamblaje de la bomba. aconsejable consultar con un cirujano plástico o un cirujano especialista en reconstrucción de las manos. © Titan Tool Inc. Todos los derechos reservados. Español...
  • Page 19 • No utilice la manguera como elemento de fuerza para tirar del equipo o levantarlo. • No levantar por la manija del carro al cargar o descargando. © Titan Tool Inc. Todos los derechos reservados. Español...

  • Page 20: Parts Listings

    Parts List Main Assembly © Titan Tool Inc. All rights reserved.

  • Page 21: High Rider Cart Assembly

    704-354 Spacer ............4 800-593 Wheel............2 704-355 Cap .............2 335-018 Plug.............2 590-508 Roll pin............2 800-036 Grommet.............2 761-178 Hex screw ...........4 710-199 Plug.............2 704-458 Frame assembly (includes items 10 and 14) ......1 704-291 Roll pin............2 © Titan Tool Inc. All rights reserved.

  • Page 22: Fluid Section Assembly

    NOTE: When using “hot” solvents, replace Viton valve stem o-ring (item 31) with optional Teflon valve stem o-ring (P/N 700-897). Install using o-ring replacement tool (P/N 700-890). © Titan Tool Inc. All rights reserved.

  • Page 23: Drive Assembly

    Electronic control assembly, 120V....1 730-260 Electronic control mounting screw 800-211 Motor assembly, 120V ........1 (not shown) ..........4 704-173A Crankshaft/gear assembly ......1 704-126 Electronic control lock washer 800-434 Baffle assembly ..........1 (not shown) ..........4 © Titan Tool Inc. All rights reserved.

  • Page 24: Low Rider Cart Assembly

    313-2641 “Titan” front label 313-1673 Warning label (injection/explosion) 313-1847 Shock hazard label 313-2395 Infinity logo label 313-2324 X-Lock label 313-2327 Xact Digital Control System label 313-2328 Xact Instruction label 313-2430 Transducer warning label © Titan Tool Inc. All rights reserved.

  • Page 25: Electrical Schematic

    NOTE: All electrical work should be performed by a Titan authorized service center. Potentiometer Transducer Transducer Jumper GREEN Fuse Ground Switch Motor AC-Motor AC-Motor BLACK AC-Line AC-Neut Surge Suppressor Control Panel Electronic Control Board Assembly WHITE WHITE © Titan Tool Inc. All rights reserved.

  • Page 26: Accessories

    S-3 Stainless Steel Airless Gun • 3900 PSI • Stainless Steel fluid passages • High Pressure Swivel • In-handle filter • 4-finger trigger pull Part No. Description 550-250 ...S-3 — 4 Finger Gun © Titan Tool Inc. All rights reserved.
  • Page 27 Notes/Nota © Titan Tool Inc. All rights reserved.

  • Page 28: Warranty

    Warranty Titan Tool, Inc., (“Titan”) warrants that at the time of delivery to the original purchaser for use (“End User”), the equipment covered by this warranty is free from defects in material and workmanship. With the exception of any special, limited, or extended warranty published by Titan, Titan’s obligation under this warranty is limited to replacing or repairing without charge...
