Installation Instructions
• Lay the dishwasher on its back. Remove the four screws
securing the toekick to the dishwasher, and remove the
toekick.
Screws
Figure I
• Remove the single screw just above and to the side of each
front leveling leg.
Screw
Figure J
Toekick
Screw
• Remove the side panels and set the dishwasher upright.
To adjust the door springs:
• Pull the spring adjustment pin out of the holes, insert in the
next highest or lowest hole and test again.
Increase
Decrease
Figure K
• Adjust both door springs to the same tension.
• Continue moving the spring pin until door is balanced.
• Replace the dishwasher side panels and proceed to Step 2.
