Safety Information
BEFORE YOU BEGIN
STOP
Read these instructions completely and
carefully.
IMPORTANT
- Observe all governing codes and
ordinances.
• Note to Installer - Be sure to leave these instructions for the
consumer's and local inspector's use.
• Note to Consumer - Keep these instructions with your
Owner's Manual for future reference.
• Skill Level - Installation of this dishwasher requires
basic mechanical, electrical and plumbing skills. Proper
installation is the responsibility of the installer. Product
failure due to improper installation is not covered under
the GE Appliance Warranty. See warranty information.
• Completion Time - 1 to 3 Hours. New installations require
more time than replacement installations.
CONTENTS
Installation Preparation
Parts Supplied ...................................................................................................3
Materials You Will Need ...............................................................................3
Tools You Will Need ........................................................................................3
Prepare Dishwasher Enclosure .................................................................4
Drain Requirements .......................................................................................4
Prepare Electrical Wiring .............................................................................5
Prepare Hot Water Line ................................................................................6
Installation Instructions
Step 1, Check Door Balance .......................................................................6
Step 1A, Adjust Door Springs .....................................................................6
Step 2, Adjust Leveling Legs .......................................................................8
Step 3, Remove Toekick ................................................................................8
Step 4, Install Power Cord ...........................................................................8
2
IMPORTANT
- The dishwasher MUST
be installed to allow for future removal from the enclosure
if service is required.
If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
Optional Accessories - See the Owner's Manual for available
custom panel kits.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.

FOR YOUR SAFETY

Read and observe all CAUTIONS and WARNINGS shown
throughout these instructions.
While performing installations described in this booklet,
gloves and either safety glasses or goggles should be worn.
For Monogram local service in your area, 1.800.444.1845.
For Monogram service in Canada 1.888.880.3030.
For Monogram Parts and Accessories, call 1.800.626.2002.
Step 5, Install 90° Elbow ...............................................................................8
Step 6, Position Water Line and House Wiring ..................................9
Step 7, Install Drain Hose Through Cabinet ........................................9
Step 8, Slide Dishwasher Partially Into Cabinet ................................9
Step 9, Position Dishwasher Under Countertop ............................10
Step 10, Level Dishwasher .......................................................................11
Step 11, Secure Dishwasher To Cabinet ............................................11
Step 12, Connect Water Supply ............................................................12
Step 13, Connect Drain Line ....................................................................12
Step 14, Connect Power Supply ............................................................13
Step 15, Pre-Test Checklist .......................................................................13
Step 16, Dishwasher Wet Test ................................................................14
Step 17, Replace Toekick ..........................................................................14
Step 18, Literature ........................................................................................14
