Before Using the EVF

Detachable Optical Loupe
1. The optical loupe attached to the EVF body can be flipped open 180 degrees or
detached completely.
2. To open the optical loupe, firmly grasp the loupe and flip upwards. When it is fully open,
the loupe will stay fixed on top of the body.
3. To completely detach the loupe from the body, simply slide the small latch to the left and lift
up the loupe. To replace the loupe, slide the small latch to the left and place the loupe
back into place.
2
180

Installing the Battery

1. The Cineroid EVF can be used with small, medium or large sized batteries. The battery
cover can only be used with the small sized batteries.
2. Remove the battery cover.
3. Push the battery in towards the direction of the arrow making sure the battery is properly
aligned in place.
4. The battery or the connectors may be damaged if not aligned properly.
5. The Canon LP-E6 battery can only be used in conjunction with the proper adapter.
