- Page 1 Cineroid E l e c t r o n i c V i e w F i n d e r User Manual Model : EVF 4L EVF 4B Cineroid...
- Page 2 SECULINE Co., Ltd Thank you for purchasing the Cineroid EVF. The Cineroid EVF (hereafter referred to as “EVF” ) is a view finder that can be mounted on any video camera with a HDMI output signal. Please thoroughly read the user manual for best operation and understanding of all of the functions of the EVF.
-
Page 3: Safety Precautions
SECULINE Co., Ltd Safety Precautions Please observe the following safety precautions as they are meant for the safe and proper use of the product to reduce the risk of accidents. Upon reading the user manual, keep it in a safe and available place. Do not face the eyecup directly into the sun as it may damage the LCD. -
Page 4: Table Of Contents
SECULINE Co., Ltd Table of Contents Safety Precautions Table of Contents Configuration Parts Before Using the EVF Detachable Optical Viewfinder Installing the Battery Connecting External Power Powering On/Off Adjusting the Diopter Connecting a HDMI Cable Connecting a Composite Cable Connection a Monitor Basic Features Operating the Menu Input Selection... - Page 5 SECULINE Co., Ltd Shooting Features Peaking Saturation (Exposure) Underscan Pixel to Pixel Monochrome B/W 4:3 Guide bar Screen Flip Setting User Controls Custom Button Functions Custom Display Setting OSD Color Setting Factory reset Product Specifications Optional Products EVF4...
-
Page 6: Configuration
Please ensure all parts are present after opening the box. B. Battery Cover C. Battery A. LCD VF + Optical Loupe D. Battery Charger E. Mini HDMI Cable F. Mini Shoe Mount Adapter G. User Manual H. Cineroid EVF Carrying Case EVF4... -
Page 7: Parts
SECULINE Co., Ltd Parts Menu Button Battery Cover Analog A/V input Power Switch Eye Cup External Speaker Feature Buttons φ Diopter Adjuster Headphone Jack 1/4”Screw Mount 3.2 inch LCD screen HDMI In HDMI Out (EVF4L only) EVF4... -
Page 8: Before Using The Evf
To replace the loupe, slide the small latch to the left and place the loupe back into place. Installing the Battery 1. The Cineroid EVF can be used with small, medium or large sized batteries. The battery cover can only be used with the small sized batteries. 2. Remove the battery cover. -
Page 9: Connecting External Power
SECULINE Co., Ltd Before Using the EVF Connecting External Power 1. External power is supplied through the use of the PA01 adapter. 2. Proper voltage for external power is 6-17V. 3. To install the PA01 adapter, first remove the battery from the body. 4. -
Page 10: Adjusting The Diopter
SECULINE Co., Ltd Before Using the EVF Adjusting the Diopter 1. When viewing through the optical loupe, the user can adjust the diopter accordingly. Turn on the EVF and verify the LCD image output. 2. Rotating the dial to the right will bring the eye cup towards you and rotating it to the left will move the eye cup away from you. -
Page 11: Connecting A Composite Cable
1. Make sure the EVF input selection is set to Composite. Please refer to 'Input Selection' on page 13. 2. You can purchase a composite cable from Cineroid or use your own cable if it is similar to the illustration below. -
Page 12: Basic Features
SECULINE Co., Ltd Basic Features Operating the Menu 1. Access the setting and features by pressing the menu button on the left side of the EVF. 2. Press the M button to select the main menu. When not in the menu, you can adjust the speaker volume by pressing the up and down arrow keys. -
Page 13: Input Selection
SECULINE Co., Ltd Basic Features Input Selection 1. You can choose between composite and HDMI for your external input selection. 2. The HDMI input can receive 480i, 480p, 576p, 720p and 1080i signals. 3. Press the M button for the main menu. Move the cursor to INPUT SELECT and press the M button. -
Page 14: Adjusting The Screen
SECULINE Co., Ltd Basic Features Adjusting the Screen 1. You can adjust the LCD brightness, contrast, and sharpness. Choose between 0-50 for the brightness and contrast and 0-10 for the sharpness. 2. Press the M button for the main menu. 3. -
Page 15: Shooting Features Peaking
SECULINE Co., Ltd Shooting Features Peaking 1. The EVF provides the peaking feature in both the Red and Sharpness mode. The Red mode displays in red and the Sharpness mode displays an outline in white. 2. To activate the peaking feature, simply press the PK button on the left side of the EVF body. -
Page 16: Saturation(Exposure)
SECULINE Co., Ltd Shooting Features Saturation(Exposure) 1. You can use the saturation feature to determine proper exposure. 2. To activate the saturation feature, press the SA button on the left side of the EVF body. Under exposed areas are displayed in white and over exposed areas are displayed in the black diagonal lines. -
Page 17: Pixel To Pixel
SECULINE Co., Ltd Shooting Features Pixel to Pixel 1. Enabling pixel to pixel eliminates the need for you to zoom in/out of your native video. 2. If the native video is larger than the LCD resolution then that creates a zooming effect. Conversely, if the native video is smaller than the LCD resolution then that creates a scale-down effect. -
Page 18: 4:3 Guide Bar
SECULINE Co., Ltd Shooting Features 4:3 Guide bar 1. The aspect ratio of the EVF screen is 16:9. Activating the guide bar will provide a 4:3 ratio by making both ends of the screen area a little darker. 2. Once you active the guide bar from within the menu, the right side and left side of the screen area will become slightly darker. -
Page 19: Setting User Controls
SECULINE Co., Ltd Setting User Controls Custom Button Functions 1. The left side of the EVF body contains the buttons PK, F1, F2, SA. The factory default for these buttons are peaking (PK), monochrome (F1), underscan (F2), and saturation (SA). 2. -
Page 20: Custom Display Setting
SECULINE Co., Ltd Setting User Controls Custom Display Settings 1. You can select to view the current state of the battery usage, volume, etc. on the LCD. 2. Press the M button for the main menu and select STATUS DISPLAY to view the options. 3. -
Page 21: Product Specifications
SECULINE Co., Ltd Product Specifications Size 3.2inch TFT LCD 800 x 480 Resolution Color 16.7M Viewing angle H: 180 degrees, V: 180 degrees 69.6(H) x 41.76(V)mm Display area HDMI (480i/480p/576p/720p/1080i) Input Composite Video/Stereo Audio Video output HDMI (480i/480p/720p/1080i/1080p) 3.5φ Analog stereo Phone Jack Audio out Internal speaker... -
Page 22: Optional Products
SECULINE Co., Ltd Optional Products ○External power adapter External power or Canon LP-E6 battery can be used. ○HDMI Cable Plug form Model Length ○Mini ball head Model Weight Material Mini ball head MBH-P Reinforced plastic Mini ball head MBH-M Metal Model Length Plug form... - Page 23 SECULINE Co., Ltd MEMO EVF4...
- Page 24 We will strive to create the best products and provide superb service. Customer Support Center Seculine Co., LTD. Tel +82.2.850.3021 / Fax +82.2.850.3027 Rm.510, Kolon Science Valley #2, Guro-dong, 811, Guro-gu, Seoul, 152-878, Korea Homepage www.cineroid.com E-mail support@secu-line.com EVF1.0 Printed in Korea...
