About the dishwasher control panel.
You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance
may vary from your model.
PDW8100–PDW8800 Series
3
PDW9200–PDW9800 Series
2
Control Settings
1
Status Indicator Lights
The Status display tells you what is happening while the dishwasher is in operation and may flash,
indicating a malfunction. The lights will come ON indicating the sequence of the dishwasher operation.
SENSING Displayed while the ExtraClean
ADD-A-DISH Displayed during prewash indicating that dishes added now will still be cleaned.
WASHING Displayed during prewash, main wash and rinse periods.
RINSING Displayed during rinse periods.
DRYING Displayed during HEATED DRY.
SANITIZED Displayed when cycle has met sanitization conditions.
2
Time Remaining Display
During operation, the display shows the minutes remaining until the cycle is complete. The display
may adjust the remaining time while the Sensing light is on. During a delay start, the display will show
hours of time remaining until the cycle starts.
3
Selections
PDW8100–PDW8800 Series: Press the pad for the desired wash cycle.
PDW9200–PDW9800 Series: Use the Arrow Pads
The light above or next to the selected pad will be ON to indicate which WASH CYCLE has been selected.
ANTI-BACTERIA Heavy 10.0 gal., 93 min.
(on some models) Medium 8.6 gal., 90 min.
4
1
3
(Indicators vary by models)
The dishwasher will adjust the selected cycle to achieve optimal performance.
CLEAN Displayed when a wash cycle is complete and enhancements are complete.
(on some models)
Light 7.2 gal., 90 min.
This cycle raises the water temperature in the final rinse to sanitize your dishware. The cycle length
will vary depending on the temperature of your inlet water.
NOTE: The Anti-Bacteria cycle is monitored for sanitization requirements. If the cycle is interrupted
during or after the main wash portion or if the incoming water temperature is so low that adequate
water heating cannot be achieved, the sanitizing conditions may not be met. In these cases, the
sanitized light will not illuminate at the end of the cycle.
NOTE: NSF-certified residential dishwashers are not intended for licensed food establishments.
6
5
4
4
Sensor is measuring the amount of soil and temperature of water.
to scroll through the wash cycles.
2
1
5
6
