Addendum K: Nano3D Upgrade; Addendum L: Nanoflash Known Issues / Limitations - Convergent Design nanoFlash User Manual

Audio Menu:
Play:
Loop Play:
Cue Play:
Loop Record:
Introduction
The nano3D Upgrade is the process of converting 2 nanoFlashes to a nano3D. An add-on purchase
is required, as well as 3D activation of the designated Master nanoFlash unit. Please see this
document for more information:
http://www.convergent-design.com/Portals/58/Documents/nanoFlash/nano3D_Upgrade.pdf
Addendum L: nanoFlash Known Issues / Limitations (ver1.6.245)
>"Delete Last Clip" option is broken in 1.6.248.
> With specific units, the use of cranking feature (Video->Crank) with MXF recordings can result in an
unexpected "Card too slow" error, even at bit rates of 100 Mbit or lower.
> During playback, timecode will sometimes momentarily be displayed incorrectly on the lcd screen.
> LTC timecode is off by 1 to 2 frames.
> Playback of MXF/MOV 18 Mbit from nanoFlash: audio is corrupted. The audio in the recorded files
is correct.
> SD live/record loop out is broken with some cameras such as the Sony PDW-700/800.
> MPG Playback from the nanoFlash: with HDMI input selected (System->Source), playback is
broken. To work around: select SDI as the source, turn the nanoFlash off and back on, and then
MPG playback will work.
> 720P24 / 25 / 30 playback from the nanoFlash is not supported at this time. Loop-through of these
formats during live or record mode is only supported with Video->E to E turned on.
> SD playback out of the HDMI port is not supported.
> Audio support: HDMI in / out: 2 channel audio support only. HD-SDI in / out supports 0, 2, 4, or 8
channel audio. SD-SDI / HDMI: 2 channel audio only (records as 24-bit 4 channel audio IMX, top 2
channels are blanked out).
nanoFlash
No special audio settings required for 3D. Refer to Audio menu discussion in
Audio section, pg 17.
For playback, other than playback of the last clip recorded.
You may select the clip or file to be played in this menu item.
Select the same clip or file on both the Master and the Slave.
Select Loop Play|All to enable continuous playback, with the video looping on playback.
Select Loop Play|Off, to stop playback when the last file on the card has finished
playback.
Loop Play|All is supported in both 2D and 3D modes.
Not for use in 3D mode.
Not for use in 3D mode.
Addendum K: nano3D Upgrade (ver1.6.226)
52
