A wide range of accessories discussed below are available through

http://nanoflash.net/

Compact Flash Cards (Use only the qualified Compact Flash cards at specified bit rates):

see pg 4 for qualified cards. CF cards are widely available on the internet.

Compact Flash Readers

1. Lexar FW-800

2. Delkin

3. PCI Express CF Readers

Remote Control / LTC Timecode

Remote tally light button cable for 10-pin hirose connector (available from Convergent

Design), for starting / stopping record in "Remote" trigger mode. Please note that when

starting record via the remote, the nanoFlash generally reacts right away. When

stopping record, you must hold down the remote button for 3 to 5 seconds before the

record stop is initiated, to help prevent accidentally stopping the record.

A cable is also available to allow 10-pin hirose to bnc connector LTC timecode input.

A combination cable can be made for both remote control and LTC Timecode into the

10-pin hirose connector.

Hard Disk Drive Backup Devices

1. NexTo Drive: 500 GB portable CF drive for intermediary offloading of footage – holds 15 32GB

CF cards' worth of data. Connects to computer via USB or ESATA for transfers. Please

consider using such a drive as a backup storage device before inserting CF card with

recorded video into a CF reader attached to a computer.

http://www.nextodi.co.kr/en/product/eXtreme_en.html

http://www.cvc.de/index.asp?haupt=http://www.cvc.de/shop/asp/ArtikelDetails_sql_2.asp?

Nummer=8851&Sprache=D

Batteries for powering nanoFlash

1) 2 cell lithium ion with attached 4 pin hirose connector and charger (available from Convergent

Design), provides about 3 hours recording time

2) Swit : for EX1 / EX3 and nanoFlash (requires a d-tap converter cable to 4 pin Hirose power

connector, available from Convergent Design)

http://dolgin.net/Battery_Charger_TC400-EX.htm#SWITS8U62

3) Anton Bauer, IDX (with d-tap to 4-pin hirose)

4) nanoFlash can also be powered from professional camera batteries with 2-pin hirose

connector (with 4-pin to 2-pin hirose)

Battery Cables available from Convergent Design

1. 4-pin hirose to d-tap

2. 4-pin hirose to 2-pin hirose

3. 4-pin hirose to XLR
