-- T-Lapse
-- Crank
-- HDMI Rx Color
-- 35Mb Width
-- Screen Tally
-- Flip V
-- Flop H
-- 3D
--- Enable
--- Combine
--- Record Combined [Record left/right images combined as a single clip on Master unit]
--- Play Ref
--- Frame Shift
- Audio
-- In
-- Analog Settings
--- Mix in
--- Gain in
--- Gain out
-- Record Channels
-- Monitor Channels
Play
Loop Play
Cue Play
Loop Record
Addendum I: nanoFlash Serial RS232 Remote Control (ver1.6.226)
Introduction
The nanoFlash can be controlled externally, from the Remote port with a cable connected to a custom
Rs232 controller (the controller is not provided by Convergent Design) . An add-on cost is associated
with activating this functionality. Please contact our Sales or Support department if you are
interested.
nanoFlash
[Special mode, Record 1 frame every HH:MM:SS period]
[Special mode, slow/fast motion effect based on: Record rate, Crank rate]
[HDMI input only: Full or Legal]
[35 Mbit or below HD 1080 recording only: set width to 1920 or 1440]
[Place red bar on output to indicate record in progress]
[Vertically invert the image for recording] [HD only]
[Horizontally invert the image for recording] [HD only]
[See "nano3D" Addendum for more details]
[Enable 3D functionality (Master 3D unit only) ]
[Combine left/right images for monitoring/record/playback]
[For 3D: Ext (External) on Master, Int (Internal) on Slave]
[Shift left image, right to left, specified number of pixels]
[Audio input source: Embedded SDI/HDMI or Analog port]
[Mono or Stereo]
[-99 to +44 dB]
[.3959 to 1.1430 dB]
[HD Record 0,2,4, or 8 channels audio (SD is always 2 channel) ]
[For headphone output: channels 1&2, 3&4, 5&6, or 7&8]
[Choose file from CF card to begin Play]
[Set Play to Loop all files]
[Special mode, Remote Play, cue to selected timecode then Play]
[Special mode, continuous record, overwrite cards as necessary]
44
