• WiFi On/Off button. Pressing and holding this button for two seconds turns the 2.4 GHz
and 5 GHz wireless radios on or off. If the Wireless LED is lit, the wireless radios are on.
If this LED is off, the wireless radios are turned off and you cannot connect wirelessly to
the router.
• WPS button. You can use this button to use WPS to add a wireless device or computer
to your wireless network. The Wireless LED blinks blue when the router is trying to add
the wireless device or computer. The LED stays solid blue when wireless security is
enabled in the router.

Rear Panel

The rear panel has the connections and buttons shown in the following figure.
USB
port
Figure 3. Router rear panel
The Reset button restores the factory settings. See
R6100 WiFi Router
Ethernet Internet
port
LAN ports 1–4
Hardware Setup
10
Power On/Off
Reset
button
Factory Settings on page 117.
Power connector
