Technical Specifications

Digital Cinema Initiatives Compliant K
Digital Cinema Camera
• 2/3" 16:9 high-dynamic range CMOS Imaging sensor with 5um pitch
• Full-raster, 2K DCI-compliant resolution progressive scan sensor
• Direct-to-Disk Recording
• AVI and Quicktime files compatible with widely spread Cineform De
coders and Iridas Products
• Removable Optical Low Pass Filter
• 12 bit A/D conversion and 48 bit digital signal processing
• 10+ F-stops dynamic range
•
180° film shutter equivalent with variable speed control
•
Sensitivity at 0 db: ISO 250 at 3200K and ISO 160 at 5600K
Other Sensitivities at 3200K: +3db ISO320 , +9db ISO640, +6db ISO500,
+12db ISO1000
Integrated Recording Software SiliconDVR
• SiliconDVR Software controlled Camera Environment
• 2K Formats: 2048x1152 (12,16,18,21,23.97,24,25 fps)
DCI 2048x1080 (12,16,18,21,23.97,24,25,29.97,30 fps)
Scope 2048x856
HD Formats: 1920x1080 (12,16,18,21,23.97,24,25,29.97,30 fps)
1280x720 (12,16,18,21,23.97,24,25,29.97,30,40,50
,59.94,60,72,85 fps)
• Special Formats: 960x540 (150 fps)
• Overcranking and undercranking for special effects (12~72fps)
• Time-Lapse Recording
• Visually lossless CineForm RAW™ wavelet-based codec using SiliconDVR
recording software
(12,16,18,21,23.97,24,25,29.97,30,40 fps)
