4
Project Setup
The Open Project and New Project buttons allow the user to create a new
project or open a previously existing project.
• New Project
The project setup screen selects the location for the main project file (<proj-
ect>.sil) and all of the individual captures. The project can be stored on any
drive - exepect the system drice C:\ - with a drive letter mapped into the system
representing an internal, external or network share as long as the continuous
throughput to the drive is at least 15MB/sec.
IMPORTANT:
Do not use the C: drive as this is the system drive. Filling up this drive will dis-
able recording.
The directory tree is negotiated by selecting subdirectories to move down the
tree or the double dot (..) to move up one level. The onscreen keypad is used
to enter a project name.
For computer operation, the keyboard can be used for file name entry.
Open Project
Use this menu to access an excisiting project saved on a drive
Timecode Settings
Type: Record Run
The timecode increments only when recording; i.e. the clock does not incre-
ment if not in recording mode.
Type: Free Run
The timecode always increments.
Source: Preset
This mode uses the timecode setting from the Preset Timecode Settings dialog
area. Can be used in record or free run modes.
Source: Slave LTC
The preset timecode settings in the dialog section area ignored. The timecode
is read from the external Adrienne USB time code reader.
Source: Time of Day
In this mode, the PC clock is used.
Preset TimeCode Settings
This section is used to input the timecode.
