Note:
The on-screen Hotspots inside the picture area are touch sensitive for quick
access tools for focus and exposure control.
The picture below shows the arrangement of the hot spots. For a detailed ex-
planation of tools and the menu structure of SiliconDVR in general refer the the
chapter SiliconDVR > User Interface
False Color Exposure Meter:
Luminance Distribution in a Scene on a pixel per pixel basis. Red is clipped and
therefore overexposed. "Colour Temperature" shows the Luminance. Black/
Blue "cold" analog to low luminance, Orange/Red "warm" analog to high lumi-
nance.
Edge based Focus Aid:
Objects in Focus are marked in Red Color, whereas the rest of the picture is
turned grey.
Star/Stop Record:
Record Hotspot
Look Grading Menu:
Embedded IRIDAS Colorgrading Interface.
Focus Aid Zoom:
Zoom and pan around for critical Focus adjustments.
Histogram:
A Histogram is displayed in the bottom of the screen to measure the overall ex-
posure. As the Histogram graphically overlays the Recording Preview Picture,
the overall performance will drop. Do not use the Histogram permanently.
Full Screen Modes:
Different Fullscreen Modes to switch on/off the User Interface are accessible
here.
Look On/Off:
on/Off Toggel for 3D LUT defined in SET LOOK
On Screen Guides Selection
On Screen Guides features Overlay Masks of 16:9, 1.45:1, 2.39:1, 4:3 Safe
Area ratios.
After quitting SiliconDVR (UTILITY MENU – QUIT) , the Windows Desktop
shows up. A "SI" Folder on the Desktop links all necessary Windows Functions
such as Windows Shutdown or ActivateRaw.exe.
