2.3 Installing the CPU

1. Before you insert the 1150-Pin CPU into the socket, please check if the
PnP cap is on the socket, if the CPU surface is unclean, or if there are any
bent pins in the socket. Do not force to insert the CPU into the socket if
above situation is found. Otherwise, the CPU will be seriously damaged.
2. Unplug all power cables before installing the CPU.
1
2
A
16
B
