Short Duration Power Limit
Use this item to configure short duration power limit in watts. The default
value is [Auto].
Primary Plane Current Limit
Use this item to configure the maximum instantaneous current allowed for
the primary plane. The default value is [Auto].
GT Frequency
Configure the frequency of the integrated GPU.
GT Voltage Mode
Auto: For optimized settings. Adaptive: Add voltage to the integrated GPU
when the system is under heavy load. Override: The voltage is fixed.
GT Adaptive Voltage
Configure the fixed voltage added to the integrated GPU.
GT Voltage Offset
Configure the voltage added to the integrated GPU when the system is
under heavy load.
PCIE Spread Spectrum
Enable Spread Spectrum to reduce electromagnetic interference for pass-
ing EMI tests. Disable to achieve higher clock speeds when overclocking.
DRAM Timing Configuration
DRAM Reference Clock
Select Auto for optimized settings.
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s)
inserted and assign the appropriate frequency automatically.
FIVR Configuration
FIVR Switch Frequency Signature
Select whether to boost or lower the FIVR Switch Frequency.
FIVR Switch Frequency Offset
Configure the percentage of frequency boost or deduction.
CPU Override Voltage
Configure the voltage added to the CPU when the system is under heavy
load.
CPU Voltage Offset
Configure the dynamic CPU voltage added to the CPU.
CPU Cache Override Voltage
Add voltage to the CPU Cache when the system is under heavy load.
