Transfer and Load Data to the
Standalone Software
To transfer and load VENUE data from your system to the stand-
alone software:
1
Connect the USB storage device to your laptop. Make sure the
drive is mounted before proceeding.
2
Launch the VENUE standalone software.
3
Go to Filing > Transfer .
4
Make sure your USB disk is available in the list at right.
5 Click the
Console, Settings, Show Folders, Shows, Preset
Folders, Built-In, Plug-In
type of data you want to transfer.
Transferring a Scope Set for the standalone software
6
Click the Transfer button. The data is transferred from the
USB device to the appropriate VENUE data folders on the lap-
top.
7
If you chose Console, data is automatically loaded and ap-
plied. If you chose any other data type, go to the Filing page
and click the Load tab, and load the newly transferred data into
the Standalone software.
or Scope Set selectors to select the
Click
Creating and Editing Shows and Presets
Use the techniques explained throughout this guide to assign
routing, rename channels, and to configure other parameters.
Then do the following to save and transfer your work to a com-
plete system.
To save and transfer VENUE data from the standalone software to
the complete system:
1 Connect a USB storage device to an available USB port on
your laptop.
2 Using the tab of the Filing page, save data to disk.
Save
3
Go to the Filing page and click the
saved data to a compatible USB storage device.
4
Connect the USB storage device to an available USB port on
the complete system.
5
Use the Transfer tab of the Filing page to transfer the VENUE
data from the USB storage device.
6
Use the Load tab of the Filing page to load the transferred data.
Exporting System Information and
Patchbay Information
With Standalone software, a complete system description and/or
the contents of each Patchbay page can be exported to a text file.
These can be useful for generating an input list (line list) directly
from the system. For example, build and customize the Patchbay
for an upcoming show, then export and print the channel names
list for use during sound check.
To print a system description:
1
Go to Options > System .
2 Click the Info button and follow the on-screen instructions to
print a complete system description.
For more information, see "System Information Export" on
page 58.
To export Patchbay names:
1
Go to the page you want to export.
Patchbay
2
Click the Export Patch List
screen.
Export Patch List button
The Patchbay names appear in an open HTML file that you can
save and print, or open in an HTML-compatible application for
formatting or other modification. For more information, see
"Patch List Export" on page 126.
Chapter 23: Using the Standalone Software 239
tab, and transfer
Transfer
icon in the upper right corner of the
Click to export
as HTML
