Avid Technology S3L System Manual page 201

Recall and Edit an Existing Snapshot
view its settings and make any adjustments necessary, being sure
to re-store the snapshot before exiting Preview mode. Storing a
snapshot in Preview mode does not affect previously stored MIDI
or Plug-in data (if any).
Edit Channel and Scope Settings
rameters, or scope associated with the snapshot being previewed.
The Snapshots page displays the current snapshot name in italics
to indicate that at least one parameter has been changed, and the
Channel Faders show you the previous level for each channel in
bright red. Scope Data Type buttons and Channel Scope function-
ality remain live and active at all times (in other words, changes
made to these controls while in Preview mode will remain once
Preview mode is exited).
Add and Edit MIDI, Plug-In or Media Data
or Media data associated with the snapshot, click the
in the MIDI or Plug-Ins snapshot list, or select the options in the
Media list. With plug-ins this adds the current online plug-in set-
tings to the snapshot. If you need to update pre-existing MIDI or
plug-in data associated with a snapshot, right-click the corre-
sponding entry in the MIDI or Plug-Ins view of the Snapshots
page and choose the Update option (this option will include the
plug-in rack position, and the name of the associated snapshot).
For more information, see "Plug-Ins, MIDI and Media Data in
Preview Mode" on page 204.
Updating snapshot plug-in data
4 To undo an action made while in Preview mode, click the
Undo button on-screen. (For more information about Undo in
Preview mode, see "Making Changes to Snapshots" on
page 201.)
5
To update the currently previewed snapshot but remain in Pre-
view mode, press or click
6
Continue previewing and editing settings as needed (all snap-
shot functions are available in preview mode).
7 When you are finished and need to exit Preview mode, press
F1
(or click the on-screen
Exiting Preview mode without storing will discard the
changes made while in Preview mode (Preview mode is
cleared each time you exit). You must explicitly store changes
to update the associated snapshots.
Recall a snapshot to pre-
Edit any channel settings, pa-
To add MIDI, plug-in,
Add
Store .
Preview button).
Undo and Preview Mode
In Preview mode, you can Undo actions applied to the Snapshot
List (such as Recall, Store, New and Duplicate) without affecting
the online mix.
Multiple levels of Undo are available.
Changing Settings in Preview Mode
The system tracks any changes to settings or to the Snapshot list
while in Preview mode, but only Snapshot list actions create an
Undo point. Choosing Undo will undo the last action you took
while in Preview mode, up to a maximum of 100 levels of Undo.
Any changes made after the last Preview action are also undone
(the Snapshot screen is returned to its exact state prior to the ac-
tion that created the Undo point).
button
Changing the Snapshot List in Preview Mode
Changes made to the Snapshot list are automatically tracked and
available for Undo, regardless of whether Preview mode is en-
abled or not. This includes any Recall of snapshots triggered by
incoming MIDI or MTC while in Preview mode.
For example, if a MIDI Snapshot Recall occurs while you are in
Preview mode, the online mix will be updated with that snapshot.
Pressing Undo immediately after that Recall will undo that Snap-
shot recall and revert the online mix to its state prior to the Undo.
Consider turning off the Chase MTC option while in Preview
mode to disable all MIDI recall of snapshots. In addition, you can
always use the History feature to recover from any unexpected re-
sults.
Changing MIDI, Plug-In, and Media Data in Preview Mode
Changes made to MIDI, Plug-In, and Media data cannot be un-
done. For more information, see "Adding MIDI, Plug-In, and
Media Data to Snapshots" on page 206.
Take advantage of Tool Tips in the banner display to confirm
what action the Undo button will revert. See "Undoing Snap-
shot Commands" on page 205.
Chapter 20: Snapshots 203
