Dishwasher Installation

STEP 20: DISHWASHER WET TEST

Turn on power supply or plug power cord into outlet,
Turn on power supply or plug power cord into outlet,
if equipped.
Latch door.
Latch door.
Push "Rinse Only" pad.
Push "Rinse Only" pad.
Push Start/Reset pad one time. Dishwasher should start.
Push Start/Reset pad one time. Dishwasher should start.
Check to be sure that water enters the dishwasher. If water
Check to be sure that water enters the dishwasher. If water
does not enter the dishwasher, check to be sure that water
and power are turned on.
Check for leaks under the dishwasher. If a leak is found,
Check for leaks under the dishwasher. If a leak is found,
turn off power at the breaker, and then tighten water
connections. Restore power after leak is corrected.
Check for leaks around the door. A leak around the door
Check for leaks around the door. A leak around the door
could be caused by door rubbing or hitting against
adjacent cabinets. Reposition the dishwasher if necessary.
See Step 15.
The dishwasher will drain and turn off about 5 minutes after
The dishwasher will drain and turn off about 5 minutes after
it was started. Check drain lines. If leaks are found, turn off
power at the breaker and correct plumbing as necessary.
Restore power after corrections are made. See Steps 7
and 17.
Open dishwasher door and make sure most of the water
Open dishwasher door and make sure most of the water
has drained. If not, check that disposer plug has been
removed and/or air gap is not plugged. Also check drain
hose to be sure it is not kinked underneath or behind
dishwasher. See Step 17.
Press Start/Reset pad once again and run dishwasher
Press Start/Reset pad once again and run dishwasher
through another "Rinse Only" cycle. Check for leaks and
correct if required.

STEP 21: REPLACE TOEKICK

• Place toekick against the legs of the dishwasher.
T o e k ic k
Attachment
Screws
Figure CC
• Align the toekick with the bottom edge and make sure it is
against the fl oor.
05A-1183C
• Insert and tighten the two toekick attachment screws. The
toekick should stay in contact with the fl oor.
Tip: Reduce sound from under the dishwasher
Make sure toekick is against floor.
STEP 22: LITERATURE
• Be sure to leave complete literature package, these
Installation Instructions and product samples and/or coupons
with the consumer.
13
