The following entries are displayed on this screen:
Manual Binding Option
Host Name:
IP Address:
MAC Address:
VLAN ID:
Port:
Protect Type:
Manual Binding Table
Select:
Host Name:
IP Address:
MAC Address:
VLAN ID:
Port:
Protect Type:
Collision:
Figure 12-2 Manual Binding
Enter the Host Name.
Enter the IP Address of the Host.
Enter the MAC Address of the Host.
Enter the VLAN ID.
Select the number of port connected to the Host.
Select the Protect Type for the entry.
Select the desired entry to be deleted. It is multi-optional.
Displays the Host Name here.
Displays the IP Address of the Host.
Displays the MAC Address of the Host.
Displays the VLAN ID here.
Displays the number of port connected to the Host.
Displays the Protect Type of the entry.
Displays the Collision status of the entry.
Warning: Indicates that the collision may be caused by
the MSTP function.
Critical: Indicates that the entry has a collision with the
other entries.
