- Page 1 ® Composite Video Extender E X T - C O M P O S I T E - 1 4 1 N U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Composite Video Extender is a trademark of Gefen, LLC All trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION FEATURES INSTALLATION INSTRUCTIONS CAT5 WIRING DIAGRAM WIRING DIAGRAM SPECIFICATIONS WARRANTY... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing the Composite Extender by Gefen, LLC. The Composite Extender allows users to extend Composite video signals beyond the A/V rack. The Composite Extender Series can be used to extend a Composite signal to cover the distances up to 1000 feet. Industry standard Category 5e (CAT-5e) cable is used for the extension. -
Page 5: Features
FEATURES Features • Extends Composite video with audio up to 1000 feet (300 meters). • Power only required only on transmitter. • Plug & Play installation. • One CAT5 Cable for extension. • No Loss of Quality. Includes: (1) Composite Video Extender sender unit (1) Composite Video Extender receiver unit (1) 5V DC power supply (1) Composite Cable... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Connect the Composite output of your TV source to the input on the Composite Extender Sender Unit. Connect the Composite input of your display or projector to the Composite output on the Composite Extender Receiver Unit. Connect the CAT-5 cable between the Composite Extender sender and receiver’s CAT-5 input. -
Page 7: Cat5 Wiring Diagram
CAT5 WIRING DIAGRAM... -
Page 8: Specifications
SPECIFICATIONS Video Amplifi er Bandwidth .................. 350 MHz Input Video Signal ..................1.2 Volts p-p Input Sync Signal: ..................5 volts p-p (TTL) Horizontal Frequency Range: ................15-70 KHz Vertical Frequency Range: ................30-170 Hz Video In ..................1 RCA Composite Video Audio In ....................2 RCA L+R Audio Video Out ...................1 RCA Composite Video Audio Out ....................2 RCA L+R Audio Link Connector ...................... -
Page 10: Warranty
Gefen warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen is notifi ed within two (2) years from the date of shipment, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi... - Page 12 Rev A3 This product uses UL listed power supplies.
