Know Your 8-Cup Thermal
Carafe Coffee Maker
Parts Identification
Your product may vary slightly from illustration.
1
Filter Basket Holder
2
Thermal Carafe Lid Only – (P/N 30838B)
3
Thermal Carafe With Lid – (P/N 30837B)
4
Polarized plug
5
Digital Clock/Timer
6
ON/OFF Button
7
Illuminating ON LED
8
Base Plate
9
Carafe Handle
10
Carafe Lid Handle
11
Auto Pause and Pour Assembly
(P/N 30819B)
12
Water Level Indicator
(on side, not shown)
13
Water Reservoir
14
Coffee Maker Lid
15
Removable Filter Basket
(P/N 30820B)
