Summary of Contents for Olivetti d-Copia 120
-
Page 2: Table Of Contents
The Scanned Image is Incorrectly Positioned Printing a Watermark Unable to Scan the Image Fitting the Printed Image to the Paper Uninstalling OLIVETTI Personal MFP Series Software 33 Printing Multiple Pages on One Page Outline of the Print Status Window Index... -
Page 3: How To Use The Online Manual
How to Use the Online Manual This Online Manual provides instruction for the operation of your new unit. Please read the following explanation of how to use the Online Manual, and then search for the information that you need. For more information about computers, operating systems and Acrobat Reader, please refer to the relevant manual or help file. -
Page 4: Printing Overview
Printing Overview The flow chart shown below provides printing overview. Reference: For more information on printing, see Basic Printing. When the paper source is the paper tray, verify that the paper has been loaded before starting printing. Ensure printing has been completed before turning the power off. Do not remove the power cord before turning the unit off. -
Page 5: Basic Printing
On Windows 95/98/Me/NT 4.0, click the "OK" button. Select "Print" from the application's "File" menu. Click here. Make sure that "Olivetti d-Copia 150" is selected as the current printer. If you intend to change any print setting, click the "Preferences" button to open the printer driver setup screen. -
Page 6: Starting The Printer Driver Using The "Start" Button
Panel". click "Printers". On Windows 2000, click the "Start" button and select "Settings". Click the "Olivetti d-Copia 150" printer driver icon and select "Properties" from the "File" menu. Click "Printers and Other Hardware", and then click "Printers and Faxes". On Windows 2000, click "Printers". -
Page 7: Printer Driver Settings
To view Help for a setting, click the ( ) button in the upper right-hand corner of the window and then click the setting. The Olivetti d-Copia 150 printer driver setup screen is shown below. The settings and the image of the unit will vary depending on the model. -
Page 8: Printing A Watermark
Printing a Watermark To print a watermark, for example "CONFIDENTIAL", on your document, refer to the following steps. Open the printer driver and click the "Watermarks" tab. Reference: Basic Printing for details on how to open the printer driver. How to Print a Watermark From the "Watermark"... -
Page 9: Fitting The Printed Image To The Paper
Fitting the Printed Image to the Paper This printer driver can adjust the zoom ratio for printing according to the paper loaded in the unit. Follow the steps shown below to use this function. The instruction below assumes that you intend to print an A4 size document onto an A5 size paper. -
Page 10: Printing Multiple Pages On One
Printing Multiple Pages on One Page This feature allows you to print two or four document pages onto a single page. To use this function, open the printer driver setup screen, select "2-Up" or "4-Up" for "N-Up Printing" on the "Main" tab. The "N-Up Printing"... -
Page 11: Outline Of The Print Status Window
When printing begins, the Print Status Window activates and appears on the screen. The Print Status Window is a program designed to show the current printer status including the document name being printed and error messages. Olivetti d-Copia 150 Print Status Window Status icon Status window This icon informs you of the print status. -
Page 12: Scanning Overview
Scanning Overview The flow chart shown below provides scanning overview. The environment in which the unit's scanning function can be used is subject to certain limitations. For details, see "INSTALLING THE SOFTWARE" in the Operation Manual. Caution When scanning from TWAIN* -compliant When scanning from "Scanner and Using the unit to begin scanning*... -
Page 13: Scanning An Image From A Twain-Compliant Application
Scanning an Image from a TWAIN-Compliant Application (part 1) The OLIVETTI scanner driver conforms to TWAIN, the industry standard, making it compatible with a variety of TWAIN- compliant applications. Below is a step-by-step guide for acquiring a scanned image to the Desktop Document Manager desktop screen using the Desktop Document Manager. - Page 14 It is recommended to set Caution the scanning preferences depending on the type of the Olivetti d-Copia 150 original to be scanned, i.e., Text, Text/Graphics, Photograph, Color, Black & White. Click the "Scanning" button after setting your preferences.
- Page 15 Scanning an Image from a TWAIN-Compliant Application (part 3) Scanner Driver Settings The scanner driver setup screen consists of the "Set-up screen", which lets you select scan settings, and the "Preview screen", which shows the scanned image. For details on the scan settings, click the "Help" button to display Help. Set-up screen "Scanning Source"...
-
Page 16: Preview Screen
Scanning an Image from a TWAIN-Compliant Application (part 4) Preview screen Olivetti d-Copia 150 Preview window Click the "Preview" button in the Set-up screen to display the scanned image. You can specify the scanning area by dragging the mouse inside the window. -
Page 17: Scanning An Image From A Wia-Compliant Application (Windows Xp)
If you have WIA drivers for other devices installed Place the original you wish to scan on the original in your computer, the "Select Device" screen will table/SPF. open. Select "Olivetti d-Copia 150" and click the Reference: For information on setting an original for scanning, refer Note "OK"... - Page 18 "Cancel" button. Feeder" for the "Paper source" and specify the original size in "Page size". Scan using Olivetti d-Copia 150 If you select "Document Feeder" for the "Paper source" and click the "Preview" button, the top original in the SPF is previewed. The previewed...
-
Page 19: Scanning An Image From The "Scanner And Camera Wizard" (Windows Xp)
"ORIGINAL PLACEMENT" in the Operation Manual. Click the "start" button, click "Control Panel", click "Printers and Other Hardware", and then click Olivetti d-Copia 150 "Scanners and Cameras". Click the "d-Copia 150" icon and then click "Get pictures" in "Imaging Tasks". - Page 20 Scanning an Image from the "Scanner and Camera Wizard" (Windows XP) (part 2) Select the "Picture type" and "Paper source", and Specify a group name, format and folder for saving click the "Next" button. the image, and then click the "Next" button. If you placed the original on the original table, select JPG, BMP, TIF or PNG can be selected for the format.
- Page 21 Scanning an Image from the "Scanner and Camera Wizard" (Windows XP) (part 3) When scanning ends, the following screen will Click the "Finish" button. appear. Select the next task you wish to perform, The "Scanner and Camera Wizard" closes and the and then click the "Next"...
-
Page 22: Outline Of Button Manager
Outline of Button Manager Button Manager is a utility software to link scanning functions to the SCANNER key on the unit. This software enables you to set scanning functions to six different scan menus, which will be linked the SCANNER key on the unit. Reference: To begin scanning using the unit's operation panel, settings must be established in the Control Panel after the Button Manager is installed. -
Page 23: Button Manager Settings
Programs" ("Programs" on Windows 98/Me/2000), Note executed to let you adjust the scanning Note select "OLIVETTI Personal MFP Series", and then conditions. click "Button Manager" to start Button Manager. If an application other than "Desktop Document Manager" is selected in the "Application Selection"... -
Page 24: Identifying Unit Problems
The unit's scanning function can only be used if the unit is connected to your computer with a USB cable. Caution If you fail to solve the problem after verifying all the items listed above, please CONTENTS contact your authorized OLIVETTI service center. INDEX... -
Page 25: Check The Connection Between The Unit And Computer
Check the Connection between the Unit and Computer CHECK1 Is the interface cable compatible with the If the USB cable becomes disconnected unit and computer? If the USB cable becomes disconnected, even only once during the unit's operation, then printing and scanning may be Interface cables compatible with this unit are USB disrupted. -
Page 26: Check Your Computer
Check Your Computer Reference: Plug and Play Screen does not Appear (when the USB is connected) CHECK1 Is there enough computer memory or hard CHECK3 If your computer is connected to the unit disk space? through the parallel port, is the parallel port To use this unit, you must have an adequate (LPT) mode set to other than EPP mode? amount of hard disk space. -
Page 27: Plug And Play Screen Does Not Appear (When The Usb Is Connected)
Plug and Play Screen does not Appear (when the USB is connected) If the Plug and Play screen does not appear after you connect the unit to your computer with a USB cable and turn on the power of both devices, follow the steps below to verify that the USB port is available. Click the "start"... -
Page 28: Failed To Install The Mfp Driver (Windows 2000/Xp)
Failed to Install the MFP Driver (Windows 2000/XP) If the MFP driver cannot be installed under Windows 2000/XP, check your computer's settings according to the following procedure. Click the "start" button, and then click "Control Check the "What action do you want Windows to Panel". -
Page 29: Faint, Uneven Or Smeared Print Output
Faint, Uneven or Smeared Print Output If print output is faint, uneven or smeared, follow the steps listed below. CHECK1 Has the printer driver been specified to suit CHECK4 Is it near time to replace the TD cartridge or both paper and the print job? drum cartridge? You can select "Draft", "Normal"... -
Page 30: Characters Or Graphics Are Not Printed In Correct Position
Characters or Graphics are not Printed in Correct Position If a document is printed skewed or partly off the paper, follow the steps listed below. CHECK1 Is the paper size loaded in the tray the same CHECK3 Is the paper loaded correctly? as that specified in the printer driver? If a document is physically damaged when it is output or the image is skewed on the paper, discard... -
Page 31: Nothing Prints
( ) key twice or press the ON LINE key to make the unit ready for scanning or printing. If you still cannot print after confirming the "Olivetti d-Copia 150" printer driver icon, the printer driver may CHECK3 Is your unit selected correctly in the current not have been installed correctly. -
Page 32: Poor Scanning Result
Poor Scanning Result If you get poor quality as a result of scanning a job, and you cannot improve the quality by changing preferences, refer to the check list shown below. CHECK1 Is the original clean? CHECK4 Have you adjusted the brightness and Check your original before scanning. -
Page 33: The Scanned Image Is Incorrectly Positioned
The Scanned Image is Incorrectly Positioned If the scanned image is incorrectly positioned, refer to the check list shown below. CHECK1 Have you placed the original straight? CHECK3 Have you set the original correctly on the SPF? Place the original straight on the original table. Reference: Refer to "ORIGINAL PLACEMENT"... -
Page 34: Unable To Scan The Image
"INSTALLING THE SOFTWARE" in the Operation Manual CHECK4 Is there enough computer memory? for the order of installation of the OLIVETTI Personal MFP Your computer may not have enough available memory to hold Series software and connection of the USB cable, and the document you want to scan. -
Page 35: Uninstalling Olivetti Personal Mfp Series Software
Prints" "Unable to Scan the Image". If you still cannot solve the problem, follow the steps below to uninstall OLIVETTI Personal MFP Series software (MFP driver (printer driver/scanner driver), Button Manager), and then reinstall it. Before uninstalling OLIVETTI Personal MFP Series software, close all applications. -
Page 36: How To Use The Online Manual
Index Application Selection N-up printing Scanning Mode "Auto Scan Area Judgement" button 14 Nothing Prints Scanning Overview Scanning Source Basic Printing Outline of Button Manager Select Device Border Outline of the Print Status Window Set-up Screen "Brightness/Contrast" button Overview Settings Button Manager Print Button Manager...
